Operator’s Station 9980 Self-Propelled Peanut Combine
To engage the parking brake, press the pedal.
To release the brake, pull the handle.
Brake Pedals
The combine has two brake pedals. For field
use, leave the brake pedals unlocked. If you
are transporting the combine, lock the pedals
together. The photo shows the brake pedals
with the brake lock in the unlocked position.
IMPORTANT! The combine is equipped
with manual engage and disengage brake
pedals. Make sure you engage the
parking brake when the engine is running
and the combine is parked. NEVER leave
the combine with the engine turned off
without engaging the parking brake.
34 09/04/15 MAN141
