Amadas 9980 - SSU: Control Unit SSU

9980 Self-Propelled Peanut Combine Diagnostic Codes
SSU: Control Unit SSU (If equipped)
Control Unit SPN FM I Priority
Description
SSU 84 09 Service Alert
CAN bus message containing ground speed not
avail able.
SSU 168
03
Service Alert
SSU power (cc # 927) out of range high.
SSU 168 04 Service Alert
SSU power (cc # 927) out of range low.
SSU 628 02 Service Alert
Control unit SSU malfunction: EEPROM check sum
inval id. Clear code. Replace control unit SSU if condition
persists.
SSU 628 12 Service Alert
Control unit SSU being reprogrammed (boot block
generated). Reprogram control unit SSU. Replace control
unit SSU if condition persists.
SSU
629 12 Service Alert
Control unit SSU malfunction: watchdog timer reset. Clear
code. R eplace control unit SSU if condition persists.
SSU 630 13 Service Alert
automatic steeri ng system not calibrated.
SSU 767 09 Service Alert
CAN Bus message containing backup alarm switch
information not available.
SSU 1079
03 Information
Steering flowmeter supply (cc# 046) out of range high.
SSU 1079 04 Information
Steering flowmeter supply (cc# 046) out of range low.
SSU
1504 09 Service Alert
CAN bus message contai ning seat switch status not
avail able.
SSU 1504
14 Service Alert
Operator out of seat during automatic steering operation.
SSU 1638
09 Service Alert
CAN bus message contai ning hydraulic oil temperature
not available.
SSU 1807 02 Service Alert
Steering input device indicates clockwise rotation when
the steering flowmeter indicates counter-clockwise
rotation.
SSU 1807 03 Information
SSU sensor supply 2 (cc# 053) out of range high.
SSU 1807 04 Information
SSU sensor supply 2 (cc# 053) out of range low.
SSU 1807 05 Information
SSU sensor supply 2 (cc# 053) current out of range low -
less than 4 mA.
SSU 1807 06
Information
SSU sensor supply 2 (cc# 053) current out of range high -
greater than 20 mA.
SSU 1807 10
Service Alert
Steering position sensor 1 signals do not match steering
position sensor 2 signals. Clear code. Replace steering
encoder if condition persists.
SSU 1807 14 Information
Steering encoder 1A (cc# 054) and Steering encoder 1B
(cc# 051) indicate different steering rates. Clear code.
Replace steering encoder if condition persists.
SSU 522273 00 Service Alert
Steering valve signal (cc# 058) out of range high.
SSU 522273
01 Service Alert
Steering valve signal (cc# 058) out of range low.
SSU 522331 09 Service Alert
CAN Bus message containing multifunction control
handle position sensor information not available.
SSU 522387 07 Service Alert
Steering valve is commanded to turn combine, but
steering flowmeter indicates no oil movement.
SSU 522394 09 Service Alert
CAN bus message contai ning terrain compens ation
module information not avail able.
SSU 523651 02 Service Alert
Control unit SSU malfunction: stack overflow. Clear code.
Replace control unit SSU if condition persi sts.
MAN141 09/08/15 385
