CommandTouch Cornerpost 9980 Self-Propelled Peanut Combine
When the key is on, the fuel gauge shows the
amount of fuel remaining in the tank.
When the fuel level reaches 11% of the
remaining fuel level (approximately one hour
of operation), the low fuel icon appears on the
CommandCenter display and a buzzer sounds
four times every five minutes until fuel is
added.
The fuel tank capacity is 200 gallons.
Engine Coolant Temperature
Gauge
When the key is on, the coolant temperature
gauge
displays the operating temperature.
Three or four arrows are displayed for normal
operating temperature.
If the engine temperature icon appears on the
CommandCenter display and a buzzer
sounds, stop the engine and check the
problem immediately.
124 09/04/15 MAN141
