9980 Self-Propelled Peanut Combine Operator’s Controls
MAN141.rev1 08/05/16 55
The multi-
function handle controls the
combine’s forward and backward motion.
The handle’s palm rest is adjustable up and
down in three positions. To move the palm
rest up or down, release the lever (bottom
photo) and move the palm rest until it catches
into position.
Move the lever forward for the combine to go
forward. Move the lever to the right and
rearward to go backward
below.
All buttons are explained on the following
pages.
NOTE! If the hydro charge pressure
warning comes on in the armrest display
panel when the lever is moved, check the
hydrostatic/hydraulic oil level and replace
the filter. If this does not correct the
problem, see your AMADAS/John Deere
dealer.
