Operator’s Station 9980 Self-Propelled Peanut Combine
Emergency Exit
If you ever need to exit the cab and cannot go
through the door:
1. Pull the tab indicated.
2.
Pull the rubber rope from around the
window.
3. Push the window out and allow it to fall to
the ground.
See your AMADAS/John Deere
dealer for
window replacement.
Fire Extinguisher
Although not supplied by AMADAS, it is highly
recommended that two rechargeable 10 lb.
ABC type dry chemical fire extinguishers be
installed on your combine.
Read the label on the extinguisher and
become familiar with the instructions on how to
use and maintain it. Once the extinguisher is
discharged, no matter for how long, it must be
recharged.
Right-Hand Side Cab Access
Raise the feeder house and lower the feeder
house safety stop.
Use handhold, rails, and step to move around
cab.
Window
tab
Safety stop
26 09/04/15 MAN141
