9980 Self-Propelled Peanut Combine Prestarting Checks
Hydrostatic/Hydraulic Oil
Level
Check the hydrostatic/hydraulic oil level with
the header on the ground
retracted. The oil level must be at the top of
the sight glass with the feeder house fully
lowered. Add oil as needed, but do not
overfill.
Shut OFF engine, set the parking brake and
remove the key before checking the hydraulic
oil at the engine gear case. The oil must be
above ADD mark on dipstick.
MAN141 09/04/15 161
