9980 Self-Propelled Peanut Combine Lights and Signals
Field Lights/Side Finder Lights
When the field lights switch is turned on:
•
If the turn signal is in the right signal
position, the
right side finder light (top
photo) turns on.
•
If the turn signal is in the left signal
position, the left side finder light (bottom
photo) turns on with the field lights switch.
The field lights switch also controls the light
on the unloading conveyor.
NOTE! The conveyor light comes on
automatically after the conveyor has been
extended more than 50%.
MAN141 09/04/15 149
