Amadas 9980 - Header Lift Switch

9980 Self-Propelled Peanut Combine Operator’s Controls
MAN141.rev1 08/05/16 59
Header Lift Switch
The header lift swit
ch raises and lowers the
header as follows:
•
Press and hold the top of the button to
raise the header.
• Press and hold the bottom of the button to
lower the header.
• The switch has two detent positions. Push
part way in to raise or lower the header
slowly; push all the way in to lower or raise
the header at a faster rate.
NOTE! For this switch to work:
•
The indicator light for the road
transport disconnect switch must be
OFF (bottom photo).
• The operator must be seated.
Header lift
Road transport
disconnect
Indicator light
