Diagnostic Codes 9980 Self-Propelled Peanut Combine
Access Diagnostic
Trouble Codes
Use this chapter to access the diagnostic
trouble code (DTC) display. Lists of all
possible codes, along with a description and
the priority of each code, begin on page 362.
DTC Lists
The following columns are included on each
list:
Control Unit
ADU – Armrest Display Unit
CAB –
Control Unit CAB and Cab Power
Module
CDU – Cornerpost Display Unit
ECU – Engine Control Unit
LC1 –
Control Unit LC1 and Left Power
Module 1
LC2 –
Control Unit LC2 and Left Power
Module 2
RCU –
Control Unit RCU and Right Power
Module
SSU – Control Unit SSU, Last Exit codes
(only if equipped with AutoTrac)
SPN
Contains the first portion (before the decimal)
of the DTC number.
FMI
Contains the portion after the decimal of the
DTC number.
Priority
Indicates one of the following:
STOP
WARNING
CALIBRATION
SERVICE ALERT
INFORMATION
Description
A description of the problem.
356 09/08/15 MAN141
