Diagnostic Codes 9980 Self-Propelled Peanut Combine
Control Unit
SPN
FMI
Priority
Description
RCU
523622
04 Information
RPC power 5 (cc# 362) less than 10.5 VDC at the right power
module input.
RCU
523648
04
Information
RPC power 4 (cc# 352) less than 10.5 VDC at the right power
module input.
RCU 523649
04
Information
RPC power 3 (cc# 332) less than 10.5 VDC at the right power
module input.
RCU 523650
04 Information
RPC power 2 (cc# 322) less than 10.5 VDC at the right power
module input.
RCU
523665 04 Information
RCU power 1 (cc# 342) at connector X132 is less than 4.0 VDC.
RCU
523666
04
Information
RCU power 1 (cc# 342) at connector X131 is less than 4.0 VDC.
RCU
523673
05
Information
Chassis ground (cc# 010) not connected to ground.
RCU
523744
03
Service Alert
HVAC compressor (cc# 941) is ON when not commanded by control
unit RCU.
RCU 523744
05
Service Alert
HVAC compressor (cc# 941) is open circuit.
RCU 523744
06
Service Alert
HVAC compressor (cc# 941) is OFF when commanded ON by
control unit RCU.
RCU 523744
14
Service Alert
HVAC compressor (cc# 941) is OFF when commanded ON by
control unit RCU, but there is no detected problem.
RCU
523810 03
Service Alert
Steering solenoid power (cc# 942) is ON when not commanded by
control unit RCU.
RCU
523810 06
Service Alert
Steering solenoid power (cc# 942) is OFF when commanded ON by
control unit RCU.
RCU
524084 03
Service Alert
Hydraulic oil temp sensor (cc# 753) is out of range -greater than 4.93
VDC .
RCU
524084 04
Service Alert
Hydraulic oil temp sensor (cc# 753) is out of range -less than 0.10
VDC .
384 09/08/15 MAN141
