9980 Self-Propelled Peanut Combine Diagnostic Codes
Control Unit
SPN
FMI
Priority
Description
RCU
523612 14
Service Alert
Right stubble light (cc# 563) is OFF when commanded ON by control unit
RCU, but there is no detected problem.
RCU
523614 03
Service Alert
Right marker lights (cc# 553) is ON when not commanded by control unit
RCU.
RCU
523614
05
Service Alert
Right marker lights (cc# 553) is open circui t.
RCU
523614 06
Service Alert
Right marker lights (cc# 553) is OFF when commanded ON by control
unit RCU.
RCU
523614 14
Service Alert
Right marker lights (cc# 553) output driver fault.
RCU
523615 03
Stop
Separator engage (cc# 301) is ON when not commanded by control unit
RCU.
RCU 523615
05 Service Alert
Separator engage (cc# 301) is open circuit.
RCU 523615
06
Service Alert
Separator engage (cc# 301) is OFF when commanded ON by control unit
RCU.
RCU
523615
14 Service Alert
Separator engage (cc# 301) is OFF when commanded ON by control unit
RCU, but there is no detected problem.
RCU
523616 03
Service Alert
Discharge beater
(#2 Stripper Cylinder) speed (cc# 611) signal voltage
feedback is out of range -greater than 4.90 VDC.
RCU
523616 04 Service Alert
Discharge beater
(#2 Stripper Cylinder)
speed (cc# 611) s ignal voltage
feedback is out of range -less than 0.10 VDC.
RCU
523617 03
Service Alert
Capacitive fuel level 2 sensor (cc# 756) is out of range -greater than 4.5
VDC .
RCU
523617 04 Service Alert
Capacitive fuel level 2 sensor (cc# 756) is out of range -less than 0.2
VDC .
RCU 523618
03 Service Alert
Capacitive fuel level 1 sensor (cc# 755) is out of range -greater than 4.5
VDC .
RCU 523618
04 Service Alert
Capacitive fuel level 1 sensor (cc# 755) is out of range -less than 0.2
VDC .
RCU 523619
03 Service Alert
Resistive fuel level 2 sensor (cc# 756) is out of range -greater than 4.5
VDC .
RCU 523619
04 Service Alert
Resistive fuel level 2 sensor (cc# 756) is out of range -less than 0.2 VDC.
RCU
523620 03 Service Alert
Resistive fuel level 1 sensor (cc# 755) is out of range -greater than 4.5
VDC .
RCU 523620
04 Service Alert
Resistive fuel level 1 sensor (cc# 755) is out of range -less than 0.2 VDC.
RCU 523621
13 Information
Threshing (Cleaning Fan Damper) clearance (c c# 833) has not been
calibrated
