Diagnostic Codes 9980 Self-Propelled Peanut Combine
Control Unit SPN
FMI Priority
RCU 1867 06 Service Alert
RPM micro power (cc# 302) is OFF when commanded ON by
Control unit RCU.
Auger
(Conveyor)
engage (cc# 319) is ON when not commanded
by control unit RCU.
RCU 3020 05 Service Alert
Auger
(Conveyor)
engage (cc# 319) is open circuit.
RCU 3020 06 Service Alert
Auger (Conveyor) engage (cc# 319) is OFF when commanded ON
by control unit RCU.
RCU
3020 14 Service Alert
Auger
(Conveyor) engage (cc# 319) is OFF when commanded ON
by control unit RCU, but there is no detected problem.
RCU 3353 03 Service Alert
Alternator field (cc# 007) is ON when not commanded by control unit
RCU.
Alternator field (cc# 007) is open circuit.
RCU
3353 06 Service Alert
Alternator field (cc# 007) is OFF when commanded ON by control
unit RCU.
RCU 3353 14 Service Alert
Alternator field (cc# 007) is OFF when commanded ON by control
unit RCU, but there is no detected problem.
RCU
3509 03 Service Alert
RCU 5V sensor supply (cc# 293) is out of range -greater than 5.5
VDC.
RCU 3509 04 Service Alert
RCU 5V sensor supply (cc# 293) is out of range -less than 4.5 VDC.
RCU 3510 03 Service Alert
RCU 8V sensor supply (cc# 297) is out of range -greater than 8.5
VDC.
RCU 8V sensor supply (cc# 297) is out of range -less than 7.5 VDC.
RCU PTC power (cc# 562) is out of range -less than 4.0 VDC.
RCU 523319
03 Service Alert
RCU 12V switched power (cc# 822) is ON when not commanded by
control unit RCU.
RCU 523319
06 Service Alert
RCU 12V switched power (cc# 822) is OFF when commanded ON
by control unit RCU.
RCU 523489 03 Service Alert
Engine service lights (cc# 531) are ON when not commanded by
right power module.
RCU 523489 05 Service Alert
Engine service lights (cc# 531) are open circuit.
RCU
523489 06 Service Alert
Engine service lights (cc# 531) are OFF when commanded ON by
right power module.
RCU
523493 12 Service Alert
Main gearcase filter (cc# 701) problem detected when engine is not
running.
Control Unit SPN FMI Prio rity
RCU 523494 03 Service Alert
Right row finder light (cc# 523) is ON when not commanded by control unit
RCU.
RCU 523494
05 Service Alert
Right row finder light (cc# 523) is open circuit.
RCU 523494 06 Service Alert
Right row finder light (cc# 523) is OFF when comm anded ON by control unit
RCU.
RCU 523501
12 Service Alert
Main gearcase pressure (cc# 703) is detected when engine is not running.
RCU 523574 03 Service Alert
Main gearcase temp sensor (cc# 754) is out of range -greater than 4.93 VDC.
RCU 523574 04 Service Alert
Main gearcase temp sensor (cc# 754) is out of range -less than 0.10 VDC.
382 09/08/15 MAN141
