Diagnostic Codes 9980 Self-Propelled Peanut Combine
Control Unit SPN FMI Priority
SSU 523698 09 Service Alert
CAN bus message containing GREENSTAR dis play AutoT rac
navigation information not available.
SSU 523766 02 Service Alert
Invalid AutoTrac activation code. Go to John Deere web site
www.stellarsupport.com and provide serial number of control unit
SSU and vehicle serial number to obtain valid activation code.
SSU 523767 09 Service Alert
CAN bus message containing resume button 2 and resume button
3 status not available.
SSU 523795 02 Service Alert
Steering valve orientation incorrect.
SSU 523795 11 Service Alert
Steering valve deadbands inconsistent.
SSU 523795 12 Service Alert
Steering valve assembly or wiring faul ty.
SSU 523795 13 Service Alert
Steering valve calibration fault. Recali brate with rear wheels off the
ground. Replace steering val ve if condition persi sts.
SSU 523810 00 Service Alert
Steering valve power (cc# 057) out of range high.
SSU 523810 01 Service Alert
Steering valve power (cc# 057) out of range low.
SSU 523821 02 Service Alert
Machine mismatch (8000/9000, or Tracks/wheels). There is a
problem with harness jumper (cc# 049)
SSU 523822 02 Service Alert
Steering flowmeter direction does not agree with steering encoder
direction.
SSU 523822 05 Service Alert
Steering flowmeter supply (cc# 046) current out of range low -less
than 20 mA.
SSU 523822 06 Service Alert
Steering flowmeter supply (cc# 046) current out of range high -
greater than 50 mA.
SSU 523822 07 Service Alert
Steering flowmeter range too small during calibration -less than
400 counts at full left or full right turn. Recalibrate. Replace
steering flowmeter i f condition persists.
SSU 523822 08 Service Alert
Steering flowmeter signal 1 (cc# 045) or steering flowmeter signal
2 (cc# 048) missing.
SSU 523822 10 Service Alert
Wheel motion detected by steering flowmeter with no Steering
input device motion.
SSU 523822 12 Service Alert
Steering flowmeter hysteresis excessive during calibration.
SSU 523822 14 Service Alert
Steering flowmeter signal 1 (cc# 045) and flowmeter si gnal 2 (cc#
893) indicate different steering rates.
SSU 523824 03 Information
Steering flowmeter signal 2 (cc# 053) out of range high.
SSU 523824 04 Information
SSU sensor supply 2 (cc# 053) out of range low.
SSU 523824 05 Information
SSU sensor supply 2 (cc# 053) current out of range low -Less than
4 mA.
SSU 523824 06 Information
SSU sensor supply 2 (cc# 053) current out of range high -greater
than 20 mA.
SSU 523824 10 Information
Steering encoder 2 signals do not match steering encoder 1
si gnals.
SSU 523824 14 Information
Steering encoder 2A (cc# 044) and steering encoder 2B (cc# 041)
indicate different steering rates.
SSU 524221 09 Service Alert
Go to John Deere web site www.stellarsupport.com and select
GREENSTAR System update.
386 09/08/15 MAN141
