Diagnostic Codes 9980 Self-Propelled Peanut Combine
Control Unit SPN FMI Priority
LC2 523552 06 Service Alert
Chaffer 1 (Elevator Fan Damper) close (cc# 307) i s OFF when
commanded ON by control unit LC2.
LC2 523561 11 Information
Left chaffer
(Elevator Fan Damper)
actuator failed calibration.
Pulses present on chaffer 1 position (cc# 809). Limit switch remains
on.
LC2 523561 03 Service Alert
Chaffer 1
(Elevator Fan Damper)
open (cc# 306) and/or chaffer 1
close (cc# 307) is ON when commanded OFF by control unit LC2.
LC2 523561 05 Service Alert
Chaffer 1
(Elevator Fan Damper)
open (cc# 306) and/or chaffer 1
close (cc# 307) is open circuit.
LC2 523561 06 Service Alert
Chaffer 1 (Elevator Fan Damper) open (cc# 306) is OFF when
commanded ON by control unit LC2.
LC2 523565 03 Service Alert
Left rear marker lights (cc# 554) output is ON when commanded
OFF by control unit LC2.
LC2 523565 05 Service Alert
Left rear marker lights (cc# 554) output is open circuit.
LC2 523565 06 Service Alert
Left rear marker lights (cc# 554) output is OFF when commanded
ON by control unit LC2.
LC2 523611 03 Service Alert
Left rear discharge light (cc# 566) is ON when commanded OFF by
left power module 2.
LC2 523611 05 Service Alert
Left rear discharge light (cc# 566) is open circuit.
LC2 523611 06 Service Alert
Left rear discharge light (cc# 566) is OFF when commanded ON by
left power module 2.
LC2 523637 03 Service Alert
Four wheel drive engage solenoid (cc# 203) is ON when
commanded OFF by left power module 2.
LC2 523637 05 Service Alert
Four wheel drive engage solenoid (cc# 203) is open circuit.
LC2 523637 06 Service Alert
Four wheel drive engage solenoid (cc# 203) is OFF when
commanded ON by left power module 2.
LC2 523665 05 Service Alert
LC2 power 1 (cc# 252) at connector X339 is less than 4.0 VDC.
Control Unit SPN FMI Priority
LC2 523666
05 Servi ce Alert
LC2 power 2 (cc# 242) at connector X342 is less than 4.0 VDC.
LC2 523673 02
Servi ce Alert
Chassis ground (c c# 010) not connected to ground.
380 09/08/15 MAN141
