9980 Self-Propelled Peanut Combine Diagnostic Codes
Control Unit
SPN FMI
Priority
Voltage of cc# 431, 433, 434 or 435 changed while operating
in automatic header height control mode.
Feeder house Raise/Lower Speed Calibration -The feeder
house did not raise when the applied current was greater than 1500mA
Feeder house Raise/Lower Speed Calibration -The feeder
house began raising when the applied current was less than 500mA
Header raise sol enoid (cc# 427) is ON when commanded OFF
by control unit LC1.
Header raise sol enoid (cc# 427) is OFF when commanded ON
by control unit LC1.
Header raise sol enoid (cc# 427) is open circuit.
Header raise sol enoid (cc# 427) is over cur rent.
Driver for header raise solenoid (cc# 427) is faulty.
Feeder house raise/lower speed cal ibration has not been
performed.
Feeder house Raise/Lower Speed Calibration -The feeder
house did not lower when the applied current was greater than 1500mA
Feeder house Raise/Lower Speed Calibration -The feeder
house began lowering when the applied current was less than 500mA
Header lower solenoid (cc# 407) is ON when commanded OFF
by control unit LC1.
LC1 1520 04 Service Alert
Header lower solenoid (cc# 407) is OFF when commanded ON
by control unit LC1.
Header lower solenoid (cc# 407) is open circuit.
Header lower solenoid (cc# 407) is over current.
Driver for header lower solenoid (cc# 407) is faulty.
LC1
1524 03 Service Alert
Reel extend (Basket Raise)
solenoi d (cc# 418) is ON when commanded OFF by
control unit LC1.
Reel extend
(Basket Raise)
solenoid (cc# 418) is open circuit.
LC1
1524 06 Service Alert
Reel extend (Basket Raise)
solenoid (cc# 418) is OFF when commanded ON
by control unit LC1.
Driver for reel extend
(Basket Raise)
sol enoid (cc# 418) is faulty.
Control Unit SPN FMI Priority
LC1 1525 03 Service Aler t
Reel retract (Basket Lower) solenoid (cc# 419) is ON when commanded OFF
by control unit LC1.
LC1 1525 05 Service Aler t
Reel retract
(Basket Lower)
solenoid (cc# 419) is open circuit.
LC1 1525 06 Service Aler t
Reel retract (Basket Lower) solenoid (cc# 419) is OFF when commanded ON
by control unit LC1.
LC1 1525 12 Service Aler t
Driver for reel retract
(Basket Lower)
solenoid (cc# 419) is faulty.
LC1 1529 03 Service Aler t
Accumulator shutoff solenoid (cc# 484) is ON when commanded
OFF by control unit LC 1.
LC1 1529 05 Service Aler t
Accumulator shutoff solenoid (cc# 484) is open circuit.
LC1 1529 06 Service Aler t
Accumulator shutoff solenoid (cc# 484) is OFF when
commanded ON by c ontrol unit LC1.
LC1 1529 12 Service Aler t
Driver for accumulator shutoff solenoid (cc# 484) is faul ty.
LC1 1533 03 Service Aler t
Feeder house position sensor (cc# 814) is out of range -greater
than 4.5 VDC.
LC1 1533 04 Service Aler t
Feeder house position sensor (cc# 814) is out of range -less
than 0.5 VDC.
Header Calibration -center height sensor (cc# 817) raised voltage
is less than lowered voltage.
MAN141 09/08/15 375
