Diagnostic Codes 9980 Self-Propelled Peanut Combine
Control Unit SPN FMI Priority
Description
LC1 3333 17 Calibration
Feeder house Raise/Lower Speed Cali bration -The feeder
house lowered too far during cali bration and might have hit the end stop if the
calibration continued. Please repeat the calibration starting with the feeder house
lower to the ground.
LC1 3333 18 Calibration
Feeder house Height Range Cal ibration -The maximum
feeder house position sensor (cc# 814) voltage is too low -less than 3.00 VDC.
LC1
3509 03 Service Alert
LC1 sensor supply 1 (cc# 253) is too high -greater than
5.50 VDC.
LC1 3509 04 Service Aler t
LC1 sensor supply 1 (cc# 253) is too low -less than
4.50 VDC.
LC1 3510 03 Service Aler t
LC1 8 VDC sensor supply (cc# 267) is too high -greater
than 8.50 VDC.
LC1 3510 04 Service Aler t
LC1 8 VDC sensor supply (cc# 267) is too low -less
than 7.50 VDC.
LC1
3597
04 Service Alert
LC1 PTC power (cc# 606) output too low.
LC1
522312 03
Service Alert
Windshield washer pump (cc# 924) is ON when
commanded OFF by control unit LC1.
LC1
522312 05
Service Alert
Windshield washer pump (cc# 924) is open circuit.
LC1
522312
06 Service Alert
Windshield washer pump (cc# 924) is OFF when
commanded ON by control unit LC1.
LC1
522312
12 Service Alert
Driver for windshiel d washer pump (cc# 924) is faul ty.
LC1 523319
03
Service Alert
LC1 12V switched power (cc# 802) is ON when
commanded OFF by control unit LC1.
LC1 523319 06 Service Alert
LC1 12V switched power (cc# 802) is OFF when
commanded ON by control unit LC1.
Control Unit SPN
FMI
Prio rity
Description
LC1 523559
3
Service Alert
Left row finder light (cc# 524) is ON when commanded OFF
by left power module 1.
LC1
523559 5
Service Alert
Left row finder light (cc# 524) is open circuit.
LC1 523559 6
Service Alert
Left row finder light (cc# 524) is OFF when commanded ON
by left power module 1.
LC1
523560 3
Service Alert
Grain tank
(Basket)
light (cc# 526) is ON when commanded OFF by
left power module 1.
LC1 523560
5
Service Alert
Grain tank
(Basket)
light (cc# 526) is open circuit.
LC1 523560
6
Service Alert
Grain tank
(Basket) light (cc# 526) is OFF when commanded ON by
left power module 1.
LC1 523562
3
Service Alert
Conveyor (Collection) auger s peed (cc# 608) has no signal. Sensor
voltage out of range high.
LC1
523562 4
Service Alert
Conveyor
(Collection)
auger s peed (cc# 608) has no signal. Sensor
voltage out of range low.
