9980 Self-Propelled Peanut Combine Diagnostic Codes
Control Unit SPN
FMI Priority
LC1
523585
03
Servic e Alert
Reel speed adjust solenoid (cc# 425) is ON when commanded
OFF by control unit LC1.
LC1
523585 04
Servic e Alert
Reel speed adjust solenoid (cc# 425) is OFF when
commanded ON by control unit LC1.
LC1 523585 05
Servic e Alert
Reel speed adj ust solenoid (cc# 425) is open circuit. (Function not
used b y Amadas but there is a resistor at LC1 connector tying
cc# 423 to cc# 425 to eliminate alarm. If Alarm is present then
resistor has failed.)
LC1 523585
06 Servic e Alert
Reel speed adj ust solenoid (cc# 425) is over current. (Function
not used by Amadas but there is a resistor at LC1 connector
tying cc# 423 to cc# 425 to eliminate alarm. If Alarm is present
then resistor has failed.)
LC1
523585
12 Servic e Alert
Driver for reel speed adjust solenoid (cc# 425) is faulty. (Function
not used by Amadas but there is a resistor at LC1 connector
tying cc# 423 to cc# 425 to eliminate alarm. If Alarm is present
then resistor has failed.)
LC1
523587
03 Servic e Alert
Unload solenoid (cc# 458) i s ON when c ommanded OFF by
control unit LC1.
LC1 523587 05 Servic e Alert
Unload solenoid (cc# 458) i s open circuit.
LC1 523587 06 Servic e Alert
Unload solenoid (cc# 458) i s OFF when commanded ON by
control unit LC1.
LC1 523587 12 Servic e Alert
Driver for unload solenoid (cc# 458) is faulty.
LC1 523589 03 Servic e Alert
Unloading auger (Conveyor) light (cc# 525) is ON when
commanded OFF by control unit LC1.
LC1 523589 05 Servic e Alert
Unloading auger (Conveyor) light (cc# 525) is open circuit.
LC1 523589 06 Servic e Alert
Unloading auger (Conveyor) light (cc# 525) is OFF when
commanded ON by control unit LC1.
LC1
523589 12 Servic e Alert
Driver for unloading auger (Conveyor)
light (cc# 525) is faulty.
MAN141 09/08/15 377
