Diagnostic Codes 9980 Self-Propelled Peanut Combine
Control Unit SPN FMI Priority Description
CAB 1549 03 Warning
Temperature door position (cc# 774) is out of range -greater
than 4.5 VDC.
CAB 1549 04 Warning
Temperature door position (cc# 774) is out of range -less
than 0.1 VDC.
CAB 1549 06 Warning
Temperature door actuator high (cc# 771) is OFF when
commanded ON by control unit CAB.
CAB 1549 12 Warning
Temperature door has not completed the movement
requested by the control unit CAB.
CAB 1549 13
Information
Temperature door has not been calibrated.
CAB 1549 16
Calibration
Temperature door position (cc# 774) is out of range when
fully open -greater than 1.00 VDC.
CAB 1549 18
Calibration
Temperature door position (cc# 774) is out of range when
fully closed -less than 4.00 VDC.
CAB 1865 11 Warning
One of the following conditions occurred:
Key switch run (cc# 013) is ON when key switch accessory
(cc# 011) and key switch start (cc# 104) is OFF.
Key switch start (cc# 104) is ON when key switch run
(cc# 013) is OFF.
Key switch start (cc# 104) is ON when key switch accessory
(cc# 011) is ON.
CAB 1867 06 Warning
Cab power module micro power (cc# 012) is OFF when
commanded ON by control unit CAB.
CAB 2348 03 Warning
Cab roof lights 3, 4 high (cc# 585) is ON when commanded
OFF by control unit CAB.
CAB 2348 05 Warning
Cab roof lights 3, 4 high (cc# 585) is open circuit.
CAB 2348 06 Warning
Cab roof lights 3, 4 high (cc# 585) is OFF when commanded ON
by control unit CAB.
CAB 2368 03 Warning
Left turn/trailer indicator (cc# 569) is ON when commanded OFF
by control unit CAB.
CAB 2368 06 Warning
Left turn/trailer indicator (cc# 569) is OFF when commanded ON
by control unit CAB.
CAB 2370 03 Warning
Right turn/combine indicator (cc# 597) is ON when commanded
OFF by control unit CAB.
CAB 2370 06 Warning
Right turn/combine indicator (cc# 597) is OFF when commanded
ON by control unit CAB.
CAB 2386 03 Warning
Front beacon light (cc# 573) is ON when commanded OFF by
control unit CAB.
CAB 2386 05 Warning
Front beacon light (cc# 573) is open circuit.
CAB 2386 06 Warning
Front beacon light (cc# 573) is OFF when commanded ON
by control unit CAB.
CAB 2876 11 Warning
Right turn signal (cc# 513) and left turn signal (cc# 514) are
ON at the same time.
CAB 3509 03 Warning
Control unit CAB sensor supply 1 (cc# 233) is out of range
-greater than 5.5 VDC.
CAB 3509 04 Warning
Control unit CAB sensor supply 1 (cc# 233) is out of range
-less than 4.5 VDC.
