9980 Self-Propelled Peanut Combine Diagnostic Codes
Control Unit
SPN FMI
Priority Description
CAB 3510
03
Warning
Control unit CAB sensor supply 2 (cc# 243) is out of range -greater
than 5.5 VDC.
CAB 3510
04
Warning
Control unit CAB sensor supply 2 (cc# 243) is out of range -less than
4.5 VDC.
CAB 3597
06 Information
CAB protected power (cc# 552) is out of range -less than 4.0 VDC.
CAB 523319 03
Stop
CAB switched power (cc# 932) is ON when commanded OFF by
control unit CAB.
CAB 523319 06
Warning
CAB switched power (cc# 932) is OFF when commanded ON by
control unit CAB.
CAB 523490 03
Warning
High idle indicator (cc# 529) has voltage present when control unit
CAB has turned low side driver ON.
CAB 523490 06
Warning
High idle indicator (cc# 529) has no voltage present when control unit
CAB has turned low side driver OFF.
CAB 523491 03
Warning
Mid idle indicator (cc# 528) has voltage present when control unit
CAB has turned low side driver ON.
CAB 523491
06 Warning
Mid idle indicator (cc# 528) has no voltage present when control unit
CAB has turned low side driver OFF.
CAB 523492
03 Warning
Low idle indicator (cc# 527) has voltage present when control unit
CAB has turned low side driver ON.
CAB 523492
06 Warning
Low idle indicator (cc# 527) has no voltage present when control unit
CAB has turned low side driver OFF.
CAB 523622 04 Information
Cab power module power 5 (cc# 062) less than 10.5 VDC at the
CPM input.
CAB 523623 03 Warning
Switched auxiliary power 1 (cc# 071) is ON when commanded OFF
by control unit CAB.
CAB 523623 06 Warning
Switched auxiliary power 1 (cc# 071) is OFF when commanded ON
by control unit CAB.
CAB 523624
03 Warning
Cab roof lights 3 ,4 (cc# 584) is ON when commanded OFF by
control unit CAB.
CAB 523624
05 Warning
Cab roof lights 3, 4 (cc# 584) is open circuit.
CAB 523624 06 Warning
Cab roof lights 3, 4 (cc# 584) is OFF when commanded ON by
control unit CAB.
CAB 523625 00 Calibration
Fan speed adjust (cc# 074) is out of range at maximum -greater than
4.25 VDC.
CAB 523625 01 Calibration
Fan speed adjust (cc# 074) is out of range at minimum -less than
0.25 VDC.
CAB 523625 03 Warning
Fan speed adjust (cc# 074) is out of range -greater than 4.50 VDC.
CAB 523625 04 Warning
Fan speed adjust (cc# 074) is out of range -less than 0.50 VDC.
CAB 523625 13 Information
Fan speed adjust (cc# 074) has not been calibrated.
CAB 523625 16
Calibration
Fan speed adjust (cc# 074) is out of range at minimum -greater than
1.00 VDC.
CAB 523625
18 Calibration
Fan speed adjust (cc# 074) is out of range at maximum -less than
4.00 VDC.
CAB 523626 14 Warning
Right rear red light (cc# 517) output driver fault.
CAB 523627 14 Warning
Left rear red light (cc# 518) output driver fault.
MAN141 09/08/15 365
