Diagnostic Codes 9980 Self-Propelled Peanut Combine
SPN FMI Priority Description
Left amber lights (cc# 516) is ON when commanded OFF by control
unit CAB.
Left amber lights (cc# 516) is open circuit.
Left amber lights (cc# 516) is OFF when commanded ON by
control unit CAB.
Cab roof lights 1, 6 (cc# 581) is ON when commanded OFF
by control unit CAB.
Cab roof lights 1, 6 (cc# 581) is open circuit.
Cab roof lights 1, 6 (cc# 581) is OFF when commanded ON
by control unit CAB.
Recirculation fan power (cc# 082) is ON when commanded
OFF by control unit CAB.
Recirculation fan power (cc# 082) is open circuit.
Recirculation fan power (cc# 082) is OFF when commanded
ON by control unit CAB.
Cab roof lights 2, 5 (cc# 583) is ON when commanded
OFF by control unit CAB.
Cab roof lights 2, 5 (cc# 583) is open circuit.
Cab roof lights 2, 5 (cc# 583) is OFF when commanded
ON by control unit CAB.
Right amber lights (cc# 515) is ON when commanded OFF by
control unit CAB.
Right amber lights (cc# 515) is open circuit.
Right amber lights (cc# 515) is OFF when commanded
ON by control unit CAB.
Hazard lights indicator (cc# 555) is ON when commanded
OFF by control unit CAB.
Hazard lights indicator (cc# 555) is OFF when commanded
ON by control unit CAB.
4WD low indicator (cc# 536) has voltage present when control unit
CAB has turned low side driver ON.
4WD low indicator (cc# 536) has no voltage present when
control unit CAB has turned low side driver OFF.
4WD high indicator (cc# 543) has voltage present when
control unit CAB has turned low side driver ON.
4WD high indicator (cc# 543) has no voltage present when
control unit CAB has turned low side driver OFF.
Road/field indicator (cc# 534) has voltage present when
control unit CAB has turned low side driver ON.
366 09/08/15 MAN141
