Amadas 9980 - Page 379

9980 Self-Propelled Peanut Combine Diagnostic Codes
Control Unit
SPN FMI Priority Description
CAB 523638 06 Warning
Road/field indicator (cc# 534) has no voltage present when
control unit CAB has turned low side driver OFF.
CAB 523639 03 Warning
Right rear red light (cc# 517) is ON when commanded
OFF by control unit CAB.
CAB
523639 05 Warning
Right rear red light (cc# 517) is open circuit.
CAB 523639 06 Warning
Right rear red light (cc# 517) is OFF when commanded
ON by control unit CAB.
CAB 523640 03 Warning
Left rear red light (cc# 518) is ON when commanded
OFF by control unit CAB.
CAB 523640 05 Warning
Left rear red light (cc# 518) is open circuit.
CAB 523640 06 Warning
Left rear red light (cc# 518) is OFF when commanded
ON by control unit CAB.
CAB 523641 00
Calibration
Temperature adjust (cc# 075) is out of range at maximum
-greater than 4.25 VDC.
CAB 523641 01
Calibration
Temperature adjust (cc# 075) is out of range at minimum
-less than 0.25 VDC.
CAB 523641 03 Warning
Temperature adjust (cc# 075) is out of range -greater than 4.50 VDC.
CAB
523641 04 Warning
Temperature adjust (cc# 075) is out of range -less than 0.50 VDC.
CAB 523641 13
Information
Temperature adjust (cc# 075) has not been calibrated.
CAB 523641 16
Calibration
Temperature adjust (cc# 075) is out of range at minimum
-greater than 1.00 VDC.
CAB 523641 18
Calibration
Temperature adjust (cc# 075) is out of range at maximum -less
than 4.00 VDC.
CAB 523642 03 Warning
CAN Bus message from control unit RCU that HVAC high pressure
switch is open.
CAB 523643 03 Warning
Handle position 1 (cc# 935) is out of range -greater than 4.5 VDC.
CAB 523643 04 Warning
Handle position 1 (cc# 935) is out of range -less than 0.5 VDC.
CAB
523644 11 Warning
One of the following conditions occurred:
Separator engage ON switch (cc# 933) and separator engage OFF
switch (cc# 931) are ON at the same time.
Separator engage ON switch (cc# 933) and separator engage OFF
switch (cc# 931) are OFF at the same time.
CAB
523645 11 Warning
One of the following conditions occurred:
Header engage switch (cc# 988) is ON when both header forward
switch (cc# 987) and header reverse switch (cc# 989) are OFF.
Header engage switch (cc# 988) is OFF when either header
forward switch (cc# 987) or header reverse switch (cc# 989) is ON.
Header engage switch (cc# 988) is ON when both header forward
switch (cc# 987) and header reverse switch (cc# 989) are ON.
CAB 523646 03 Warning
Outlet air temperature sensor output (cc# 761) is out of range
-greater than 4.93 VDC.
CAB 523646 04 Warning
Outlet air temperature sensor output (cc# 761) is out of range
-less than 0.10 VDC.
CAB
523647 03 Warning
Temperature door actuator high (cc# 771) and/or Temperature door
actuator low (cc# 773) is ON when commanded OFF by control unit CAB.
MAN141 09/08/15 367
