Lubrication and Maintenance 9980 Self-Propelled Peanut Combine
2000 Hours, Continued
Drain the final drives and refill to within 12
mm (1/2 “) of bottom of check hole. If you
can touch oil with your little finger, you do
not need to add oil.
Slide the transmission slide tube out of
the
block. Remove the block to drain.
Fill at the hole to within 12 mm (1/2 “) of
bottom of hole.
334 09/08/15 MAN141
