Reference Manual ADuCM356
REGISTER DETAILS: PROGRAMMABLE SWITCHES
analog.com Rev. A | 117 of 312
SWITCH MATRIX CONFIGURATION REGISTER
Address: 0x400C200C, Reset: 0x0000FFFF, Name: SWCON
Table 144. Bit Descriptions for SWCON
Bits Bit Name Settings Description Reset Access
[31:20] Reserved Reserved. 0x0 R
19 T11CON Control of T11 Switch. 0x0 R/W
1 T11 closed.
0 T11 open.
18 T10CON Control of T10 Switch. 0x0 R/W
1 T10 closed.
0 T10 open.
17 T9CON Control of T9 Switch. 0x0 R/W
1 T9 closed.
0 T9 open.
16 SWSOURCESEL Switch Control Select. Select registers to control programmable switches. 0x0 R/W
1 Switch control source. Switches controlled by DSWFULLCON, TSWFULLCON,
PSWFULLCON, and NSWFULLCON registers.
0 Dx, Tx, Px, and Nx switches controlled as groups via SWCON register.
[15:12] TMUXCON Control of Tx Switch Mux. Does not Include control of T11 to T9 switches. 0xF R/W
0000 All switches open.
0001 T1 closed, others open.
0010 T2 closed, others open.
0011 T3 closed, others open.
0100 T4 closed, others open.
0101 T5 closed, others open.
0110 Reserved.
0111 T7 closed, others open.
1000 TR1 closed, others open.
1001 All switches closed.
1010 to 1111 All switches open.
[11:8] NMUXCON Control of Nx Switch Mux. 0xF R/W
0000 NL2 closed, others open.
0001 N1 closed, others open.
0010 N2 closed, others open.
0011 N3 closed, others open.
0100 N4 closed, others open.
0101 N5 closed, others open.
0110 N6 closed, others open.
0111 N7 closed, others open.
1000 N8 closed, others open.
1001 N9 closed, others open.
1010 NR1 closed, others open.
1011 to 1110 NL closed, others open.
1111 All switches open.
[7:4] PMUXCON Control of Px Switch Mux. 0xF R/W
0000 PL2 closed, others open.
0001 PR0 closed, others open.
0010 P2 closed, others open.
0011 P3 closed, others open.
