REGISTER DETAILS: PROGRAMMABLE SWITCHES
analog.com Rev. A | 123 of 312
Table 149. Bit Descriptions for DSWSTA (Continued)
Bits Bit Name Settings Description Reset Access
0 Switch open.
1 Switch closed.
0 D1STA Status of DR0 Switch. 0x0 R
0 Switch open.
1 Switch closed.
PX SWITCH MATRIX STATUS REGISTER
Address: 0x400C21B4, Reset: 0x00000000, Name: PSWSTA
This register gives the status of the Px switches shown in Figure 27.
Table 150. Bit Descriptions for PSWSTA
Bits Bit Name Settings Description Reset Access
[31:15] Reserved Reserved. 0x0 R
14 PL2STA PL2 Switch Control. 0x0 R
0 Switch open.
1 Switch closed.
13 PLSTA PL Switch Control. 0x0 R
0 Switch open.
1 Switch closed.
12 P13STA Status of P13 Switch. 0x0 R
0 Switch open.
1 Switch closed.
11 P12STA Status of P12 Switch. 0x0 R
0 Switch open.
1 Switch closed.
10 P11STA Status of P11 Switch. 0x0 R
0 Switch open.
1 Switch closed.
9 P10STA Status of P10 Switch. 0x0 R
0 Switch open.
1 Switch closed.
8 P9STA Status of P9 Switch. 0x0 R
0 Switch open.
1 Switch closed.
7 P8STA Status of P8 Switch. 0x0 R
0 Switch open.
1 Switch closed.
6 P7STA Status of P7 Switch. 0x0 R
0 Switch open.
1 Switch closed.
5 P6STA Status of P6 Switch. 0x0 R
0 Switch open.
1 Switch closed.
4 P5STA Status of P5 Switch. 0x0 R
0 Switch open.
1 Switch closed.
3 P4STA Status of P4 Switch. 0x0 R
