AFE INTERRUPTS
analog.com Rev. A | 136 of 312
There are interrupt options available on the ADuCM356 analog
front end that can be configured to toggle the internal GPIO pin
on the digital die. The GPIO pin is connected internally and is not
bonded out of the LGA package.
INTERRUPT CONTROLLER INTERRUPTS
The interrupt controller is divided into two blocks. Each block
consists of an INTCSELx register and an INTCFLAGx register.
Only INTCSEL0 interrupts are connected to the digital die by the
internal GPIO pin. The INTCSEL1 interrupts are only used for
polling. The INTCPOL and INTCCLR registers are common to both
blocks. When an interrupt is enabled in the INTCSELx register, the
corresponding bit in the INTCFLAGx register is set. The available
interrupt sources are shown in Table 173.
CONFIGURING THE INTERRUPTS
The first step to configure the INTC interrupts is to configure the
digital die GPIO pin that connects internally to the AFE interrupt
controller output. To configure the GPIO pin, take the following
steps:
1. Configure the internal GPIO2 Pin 1 as a GPIO as follows:
DioCfgPin(pADI_GPIO2, PIN1, 0);
2. Configure the internal P2.1 pin as an input as follows:
DioIenPin(pADI_GPIO2, PIN1, 1); /* Enable
P2.1 input path. */
3. Enable External Interrupt 3 and configure for falling edge as
follows:
EiCfg(EXTINT3, INT_EN, INT_FALL); /* Fall►
ing edge. */
4. Enable the interrupt in the NVIC as follows:
NVIC_EnableIRQ(AFE_EVT3_IRQn);
When these steps are complete, the digital die is configured for
INTC interrupts. To configure the AFE INTC interrupts, first write
to the INCT0POL to configure the polarity. To enable the required
interrupt, write to the INTCSEL0 register. To clear an interrupt
source, write to the corresponding bit in the INTCCLR register.
CUSTOM INTERRUPTS
Four custom interrupt sources are selectable by the user in the
INTCSELx register, Bits[12:9]. For these custom interrupts to gen-
erate an interrupt event, write to the corresponding bit in the
AFEGENINTSTA register. It is only possible to write to this register
via the sequencer.
Table 173. Interrupt Sources Summary
INTCFLAGx Register Flag Name Interrupt Source Description
FLAG0 ADC result IRQ status.
FLAG1 DFT result IRQ status.
FLAG2 Sinc2 filter result ready IRQ status.
FLAG3 Temperature result IRQ status.
FLAG4 ADC minimum fail IRQ status.
FLAG5 ADC maximum fail IRQ status.
FLAG6 ADC delta fail IRQ status.
FLAG7 Mean IRQ status.
FLAG13 Bootload done IRQ status.
FLAG15 End of sequence IRQ status.
FLAG16 Sequencer timeout finished IRQ status (see the Timer Command section).
FLAG17 Sequencer timeout command error IRQ status (see the Timer Command section).
FLAG23 Data FIFO full IRQ status.
FLAG24 Data FIFO empty IRQ status.
FLAG25 Data FIFO threshold IRQ status, threshold value set in DATAFIFOTHRES register.
FLAG26 Data FIFO overflow IRQ status.
FLAG27 Data FIFO underflow IRQ status.
FLAG29 Outlier IRQ status, detects when an outlier is detected.
FLAG31 Attempt to break IRQ status. This interrupt is set if a Sequence B request occurs when Sequence A is running. This interrupt
indicates that Sequence B is ignored.
