Reference Manual ADuCM356

analog.com Rev. A | 289 of 312

Table 379. WUT Register Summary

Address Name Description Reset Access

0x40001400 CR0 Control 0 0x03C4 R/W

0x40001404 SR0 Status 0 0x7F88 R/W

0x40001408 SR1 Status 1 0x0078 R

0x4000140C CNT0 Count 0 0x0000 R/W

0x40001410 CNT1 Count 1 0x0000 R/W

0x40001414 ALM0 Alarm 0 0xFFFF R/W

0x40001418 ALM1 Alarm 1 0xFFFF R/W

0x40001420 GWY Gateway 0x0000 W

0x40001428 CR1 Control 1 0x01E0 R/W

0x4000142C SR2 Status 2 0xC000 R/W

0x40001430 SNAP0 Snapshot 0 0x0000 R

0x40001434 SNAP1 Snapshot 1 0x0000 R

0x40001438 SNAP2 Snapshot 2 0x0000 R

0x4000143C MOD Modulo 0x0040 R

0x40001440 CNT2 Count 2 0x0000 R

0x40001444 ALM2 Alarm 2 0x0000 R/W

0x40001488 SR6 Status 6 0x7900 R
