Reference Manual ADuCM356
REGISTER DETAILS: DIGITAL INPUTS AND OUTPUTS
analog.com Rev. A | 214 of 312
Not all bits are accessible to the user on every port. Inaccessible
bits are reserved. See Table 255 for more details on the accessible
bits.
GPIO PORT CONFIGURATION REGISTERS
Address: 0x40020000, Reset: 0x00000000, Name: GP0CON
Address: 0x40020040, Reset: 0x00000000, Name: GP1CON
Address: 0x40020080, Reset: 0x00000000, Name: GP2CON
Table 259. Bit Descriptions for GP0CON, GP1CON, GP2CON
Bits Bit Name Settings Description
1
Access
[31:30] CON15 Configuration Bits for Port x.15. See Table 255. R/W
[29:28] CON14 Configuration Bits for Port x.14. See Table 255. R/W
[27:26] CON13 Configuration Bits for Port x.13. See Table 255. R/W
[25:24] CON12 Configuration Bits for Port x.12. See Table 255. R/W
[23:22] CON11 Configuration Bits for Port x.11. See Table 255. R/W
[21:20] CON10 Configuration Bits for Port x.10. See Table 255. R/W
[19:18] CON9 Configuration Bits for Port x.9. See Table 255. R/W
[17:16] CON8 Configuration Bits for Port x.8. See Table 255. R/W
[15:14] CON7 Configuration Bits for Port x.7. See Table 255. R/W
[13:12] CON6 Configuration Bits for Port x.6. See Table 255. R/W
[11:10] CON5 Configuration Bits for Port x.5. See Table 255. R/W
[9:8] CON4 Configuration Bits for Port x.4. See Table 255. R/W
[7:6] CON3 Configuration Bits for Port x.3. See Table 255. R/W
[5:4] CON2 Configuration Bits for Port x.2. See Table 255. R/W
[3:2] CON1 Configuration Bits for Port x.1. See Table 255. R/W
[1:0] CON0 Configuration Bits for Port x.0. See Table 255. R/W
1
X is 0 for Port 0, 1 for Port 1, and 2 for Port 2.
GPIO PORT OUTPUT ENABLE REGISTERS
Address: 0x40020004, Reset: 0x0000, Name: GP0OEN
Address: 0x40020044, Reset: 0x0000, Name: GP1OEN
Address: 0x40020084, Reset: 0x0000, Name: GP2OEN
Table 260. Bit Descriptions for GP0OEN, GP1OEN, GP2OEN
Bits Bit Name Settings Description Access
[15:0] OEN Pin Output Drive Enable. R/W
0 Disable the output on the corresponding GPIO.
1 Enable the output on the corresponding GPIO.
GPIO PORT INPUT/OUTPUT PULL-UP ENABLE REGISTERS
Address: 0x40020008, Reset: 0x2, Name: GP0PE
Address: 0x40020048, Reset: 0x0002, Name: GP1PE
Address: 0x40020088, Reset: 0x0000, Name: GP2PE
