Reference Manual ADuCM356
REGISTER DETAILS: DIGITAL INPUTS AND OUTPUTS
analog.com Rev. A | 220 of 312
AFE GPIO PORT DATA OUTPUT SET REGISTER
Address: 0x400C0098, Reset: 0x0, Name: SET
Table 279. Bit Descriptions for SET
Bits Bit Name Settings Description Reset Access
[15:2] Reserved Reserved. 0x0000 R/W
[1:0] SET Set Output High for the AFE Die Port Pins (GPIOx/PWMx). Set by user code to drive the corresponding
GPIO high. Clearing this bit has no effect.
0x0 W
AFE GPIO PORT DATA OUTPUT CLEAR REGISTER
Address: 0x400C009C, Reset: 0x0, Name: CLR
Table 280. Bit Descriptions for CLR
Bits Bit Name Settings Description Reset Access
[15:2] Reserved Reserved. 0x0000 R/W
[1:0] CLR Set Output Low for the AFE Die Port Pins (GPIOx/PWMx). Each bit is set to drive the corresponding
GPIO pin low. Clearing this bit has no effect.
0x0 W
AFE GPIO PORT PIN TOGGLE REGISTER
Address: 0x400C00A0, Reset: 0x0, Name: TGL
Table 281. Bit Descriptions for TGL
Bits Bit Name Settings Description Reset Access
[15:2] Reserved Reserved. 0x0000 R/W
[1:0] TGL Toggle Output of the Port Pin. Each bit is set to invert the corresponding GPIO pin. Clearing this bit has
no effect.
0x0 W
