REGISTER SUMMARY: LOW-POWER TIA/POTENTIOSTAT AND DAC CIRCUITS
analog.com Rev. A | 88 of 312
Table 107. Low-Power Potentiostat and TIA Control Register Summary
Address Name Description Reset Access
0x400C20EC LPTIACON0 Low-power TIA control bits Channel 0 0x00000003 R/W
0x400C20E4 LPTIASW0 Low-power TIA switch configuration for Channel 0 0x00000000 R/W
0x400C20E8 LPTIACON1 Low-power TIA control bits Channel 1 0x00000003 R/W
0x400C20E0 LPTIASW1 Low-power TIA switch configuration for Channel 1 0x00000000 R/W
Table 108. Low-Power DAC Control Register Summary
Address Name Description Reset Access
0x400C2120 LPDACDAT0 Low-power DAC0 data out 0x00000000 R/W
0x400C2124 LPDACSW0 Low-power DAC0 switch control 0x00000000 R/W
0x400C2128 LPDACCON0 Low-power DAC0 control 0x00000002 R/W
0x400C212C LPDACDAT1 Low-power DAC1 data out 0x00000000 R/W
0x400C2130 LPDACSW1 Low-power DAC1 switch control 0x00000000 R/W
0x400C2134 LPDACCON1 Low-power DAC1 control 0x00000002 R/W
0x400C2050 LPREFBUFCON Low-power reference control 0x00000000 R/W
