REGISTER DETAILS: ADC CIRCUIT
analog.com Rev. A | 76 of 312
GAIN CALIBRATION VOLTAGE INPUT CHANNEL (PGA GAIN = 4) REGISTER
Address: 0x400C2278, Reset: 0x00004000, Name: ADCGAINGN4
Table 91. Bit Descriptions for ADCGAINGN4
Bits Bit Name Settings Description Reset Access
[31:15] Reserved Reserved. 0x0 R
[14:0] VALUE Gain Calibration PGA Gain 4. ADC gain correction for voltage input channels. Stored as a signed
number. Bit 14 is the sign bit and Bits[13:0] represent the fractional part.
0x4000 R/W
0x7FFF 2 (maximum positive gain adjustment).
0x4001 1.000061 (minimum positive gain adjustment).
0x4000 1.0. ADC result multiplied by 1. No gain adjustment. Default value.
0x3FFF 0.999939 (minimum negative gain adjustment).
0x2000 0.5. ADC result multiplied by 0.5.
0x0001 0.000061 (maximum negative gain adjustment).
0x0000 0. Invalid value. Results in ADC result of 0.
OFFSET CALIBRATION VOLTAGE INPUT CHANNEL (PGA GAIN = 9) REGISTER
Address: 0x400C22D0, Reset: 0x00000000, Name: ADCOFFSETGN9
Table 92. Bit Descriptions for ADCOFFSETGN9
Bits Bit Name Settings Description Reset Access
[31:15] Reserved Reserved. 0x0 R
[14:0] VALUE Offset Calibration Gain 9. ADC offset correction with PGA gain = 9. 0x0 R/W
0x3FFF 4095.75 (maximum positive offset calibration value).
0x0001 0.25 (minimum positive offset calibration value).
0x0000 0 (no offset adjustment).
0x7FFF −0.25 (minimum negative offset calibration value).
0x4000 −4096 (maximum negative offset calibration value).
GAIN CALIBRATION VOLTAGE INPUT CHANNEL (PGA GAIN = 9) REGISTER
Address: 0x400C2298, Reset: 0x00004000, Name: ADCGAINGN9
Table 93. Bit Descriptions for ADCGAINGN9
Bits Bit Name Settings Description Reset Access
[31:15] Reserved Reserved. 0x0 R
[14:0] VALUE Gain Calibration PGA Gain 9. ADC gain correction for voltage input channels. Stored as a signed
number. Bit 14 is the sign bit and Bits[13:0] represent the fractional part.
0x4000 R/W
0x7FFF 2 (maximum positive gain adjustment).
0x4001 1.000061 (minimum positive gain adjustment).
0x4000 1.0. ADC result multiplied by 1. No gain adjustment. Default value.
0x3FFF 0.999939 (minimum negative gain adjustment).
0x2000 0.5. ADC result multiplied by 0.5.
0x0001 0.000061 (maximum negative gain adjustment).
0x0000 0. Invalid value. Results in ADC result of 0.
OFFSET CALIBRATION TEMPERATURE SENSOR CHANNEL 0 REGISTER
Address: 0x400C223C, Reset: 0x00000000, Name: ADCOFFSETTEMPSENS0
