Analog Devices ADuCM356 User Manual

Reference Manual ADuCM356
REGISTER DETAILS: DIGITAL DIE WAKE-UP TIMER
analog.com Rev. A | 290 of 312
CONTROL 0 REGISTER
Address: 0x40001400, Reset: 0x03C4, Name: CR0
CR0 is the primary of two control registers for the WUT, the other being CR1. All mainstream WUT operations are enabled and disabled by the
CPU using CR0. The granularity of the WUT control is expanded by the CR1 register.
Table 380. Bit Descriptions for CR0
Bits Bit Name Settings Description Reset Access
15 WPNDINTEN Enable WPENDINT Sourced Interrupts to the CPU. This field is an enable for WUT interrupts to
the CPU, based on the WPENDINT sticky interrupt in the SR0 register.
0x0 R/W
0 Disable WPENDINT sourced interrupts to the CPU.
1 Enable WPENDINT sourced interrupts to the CPU.
14 WSYNCINTEN Enable WSYNCINT Sourced Interrupts to the CPU. WSYNCINTEN is an enable for WUT
interrupts to the CPU based on the WSYNCINT sticky interrupt source field of the SR0 MMR.
WSYNCINTEN is activated whenever the effects of a posted write to a 32 kHz sourced MMR or
MMR bit field become visible to the CPU.
0x0 R/W
0 Disable WSYNCINT sourced interrupts to the CPU.
1 Enable WSYNCINT sourced interrupts to the CPU.
13 WPNDERRINTEN Enable WPNDERRINT Sourced Interrupts to the CPU when a WUT Register Write Pending
Error Occurs. Write pending errors can be avoided by the CPU by checking the pending status
of a register in SR1 before undertaking a write to that register. If a WPNDERRINT error occurs,
and this bit is set to 1, the WUT interrupts the CPU.
0x0 R/W
0 Disable interrupts if write pending errors occur in the WUT.
1 Enable interrupts for write pending errors in the WUT.
12 ISOINTEN Enable ISOINT Sourced Interrupts to the CPU. This bit enables interrupts to the CPU based on
the ISOINT sticky interrupt source in the SR0 status register. When power loss is imminent to
all power domains on the device apart from the WUT, the WUT activates its isolation barrier so
that the WUT can continue to operate independently of the core. When power is subsequently
restored to the rest of the device, the WUT activates the ISOINT interrupt source to act as a
sticky record of the power loss event just finishing. This activation occurs as the WUT lowers its
isolation barrier when the core regains power. If enabled by this bit, the WUT interrupts the CPU
based on ISOINT. The CPU can then inspect the ISOINT field of SR0 to determine if the CPU
has recovered from a total loss of power.
0x0 R/W
0 Disable ISOINT sourced interrupts to the CPU.
1 Enable ISOINT sourced interrupts to the CPU.
11 MOD60ALMINTEN Enable Periodic MOD60ALMINT Sourced Interrupts to the CPU. This bit allows the CPU to
enable a periodic, repeating interrupt from the timer at a displacement time in WUT time units
given by the MOD60ALM bit beyond a Modulo 60 boundary.
0x0 R/W
0 Disable periodic interrupts due to Modulo 60 WUT elapsed time.
1 Enable periodic interrupts due to Modulo 60 WUT elapsed time.
[10:5] MOD60ALM Periodic Modulo 60 Alarm Time in Prescaled WUT Time Units Beyond a Modulo 60 Boundary.
This bit allows the CPU to position a periodic alarm interrupt from the WUT at any integer
number of prescaled WUT time units from a Modulo 60 boundary (roll over event) of the value in
CNT1 and CNT0. Values of 0 to 59 are allowed for MOD60ALM. If a greater value is configured,
this value is treated as zero prescaled WUT time units. Boundaries are defined when the CPU
writes a new pair of values to the CNT1 and CNT0 registers, the CPU enables the WUT from
a disabled state using CR0, Bit 0, or when the WUT is enabled by CR0, Bit 0. For example, a
value of 30 results in the Modulo 60 periodic interrupt from the WUT to be issued to the CPU at
30 time units past a Modulo 60 boundary.
0x1E R/W
4 MOD60ALMEN Enable WUT Modulo 60 Counting of Time Past a Modulo 60 Boundary. Enables the detection
of the counter passing a value of 60, whereas MOD60ALMINTEN enables the generation of a
resultant interrupt.
0x0 R/W
0 Disable determination of Modulo 60 WUT elapsed time.
1 Enable determination of Modulo 60 WUT elapsed time.
