Analog Devices ADuCM356 User Manual

Reference Manual ADuCM356
REGISTER SUMMARY: POWER MANAGEMENT UNIT
analog.com Rev. A | 27 of 312
Table 21. Digital Die Power Management Register Summary (PMG0 Stack)
Address Name Description Reset Access
0x4004C000 IEN Power supply monitor interrupt enable 0x00000000 R/W
0x4004C004 PSM_STAT Power supply monitor status 0x2100 W1C
0x4004C008 PWRMOD Power mode 0x00000000 R/W
0x4004C00C PWRKEY Key protection for PWRMOD and SRAMRET 0x00000000 W
0x4004C014 SRAMRET Control for retention SRAM during hibernate mode 0x00000000 R/W
0x4004C044 CTL1 High-power buck control 0x00000000 R/W
0x4004C260 SRAM_CTL Control for SRAM parity and instruction SRAM 0x80000000 R/W
0x4004C264 SRAM_INITSTAT Initialization status 0x00000001 R/W
Table 22. Analog Die Power Management Register Summary (ALLON Stack)
Address Name Description Reset Access
0x400C0A00 PWRMOD Power modes 0x0001 R/W
0x400C0A04 PWRKEY Key protection for PWRMOD 0x0000 R/W
