Reference Manual ADuCM356
REGISTER DETAILS: SPI0/SPI1
analog.com Rev. A | 244 of 312
STATUS REGISTERS
Address: 0x40004000, Reset: 0x0800, Name: SPI0_STAT
Address: 0x40024000, Reset: 0x0800, Name: SPI1_STAT
Table 306. Bit Descriptions for SPI0_STAT, SPI1_STAT
Bits Bit Name Settings Description Reset Access
15 RDY Detected an Edge on Ready Indicator for Flow Control. This bit indicates that there was an active edge
on the P0.3 line depending on the flow control mode. If SPIx_FLOW_CTL, Bits[1:0] = 0b10, this bit is set
whenever an active edge is detected on the P0.3 signal. If SPIx_FLOW_CTL, Bits[1:0] = 0b11, this bit is
set if an active edge is detected on the MISO signal.
0x0 R/W1C
0 If SPIx_FLOW_CTL, Bits[1:0] = 0b00 or 0b01. The active edge (rising or falling) is determined by
SPI_FLOW_CTL, Bit 4.
1 When SPIx_IEN, Bit 11 is set to 1, this bit causes an interrupt, which is only cleared by writing 1 to this bit.
14 CSFALL Detected a Falling Edge on Chip Select in Target Continuous Mode. This bit causes an interrupt when
SPIx_IEN, Bit 8 is set to 1, which can be used to identify the start of an SPI data frame.
0x0 R/W1C
0 Cleared to 0 when a 1 is written to this bit.
1 Set when there is a falling edge on chip select line. Used to identify the start of an SPI data frame.
13 CSRISE Detected a Rising Edge on Chip Select in Target Continuous Mode. This bit causes an interrupt when
SPIx_IEN, Bit 8 is set to 1.
0x0 R/W1C
0 Cleared to 0 when a 1 is written to this bit or when SPIx_CTL, Bit 0 is cleared to 0.
1 Set when there is a rising edge on the chip select line. This bit can be used to identify the end of an SPI
data frame.
12 CSERR Detected a Chip Select Error Condition. 0x0 R/W1C
0 Cleared to 0 when a 1 is written to this bit.
1 Set when the chip select line is deasserted abruptly, even before the full byte of data is transmitted
completely. This bit causes an interrupt.
11 CS Chip Select Status. This bit reflects the actual chip select status as seen by the SPI module. This bit uses
SCLK to PCLK synchronization. As such, there is a slight delay when chip select changes state.
0x1 R
0 Chip select line is low.
1 Chip select line is high.
[10:8] Reserved Reserved. 0x0 R
7 RXOVR SPI Receive FIFO overflow. 0x0 R/W1C
0 Cleared to 0 when a 1 is written to this bit or when SPIx_CTL, Bit 0 is cleared to 0.
1 Set when the receive FIFO is already full when new data is loaded to the FIFO. This bit generates an
interrupt if SPIx_IEN, Bit 10 = 1, except when SPIx_CTL, Bit 12 is set.
6 RXIRQ SPI Receive IRQ. Not available in DMA mode. 0x0 R/W1C
1 Cleared to 0 when a 1 is written to this bit or when SPIx_CTL, Bit 0 is cleared to 0.
0 Set when a receive interrupt occurs. This bit is set when TIM in SPIx_CTL, Bit 6 is cleared and the
required number of bytes is received.
5 TXIRQ SPI Transmit IRQ. Status bit. This bit is not available in DMA mode. 0x0 R/W1C
0 Cleared to 0 when a 1 is written to this bit or when SPIx_CTL, Bit 0 is cleared to 0.
1 Set when a transmit interrupt occurs. This bit is set when SPIx_CTL, Bit 6 is set and the required number
of bytes is transmitted.
4 TXUNDR SPI Transmit FIFO Underflow. 0x0 R/W1C
0 Cleared to 0 when a 1 is written to this bit or when SPIx_CTL, Bit 0 is cleared to 0.
1 Set when a transmit is initiated without any valid data in the transmit FIFO. This bit generates an interrupt
when SPIx_IEN, Bit 9 = 1 except when SPIx_CTL, Bit 13 is set.
3 TXDONE SPI Transmit Done in Read Command Mode. 0x0 R/W1C
0 Cleared to 0 when 1 is written to this bit or when SPIx_CTL, Bit 0 is cleared to 0.
1 Set when the entire transmit is completed in a read command. This bit generates an interrupt if SPIx_IEN,
Bit 12 is set, and is only valid if SPIx_RD_CTL, Bit 0 is set.
