REGISTER SUMMARY: GENERAL-PURPOSE TIMERS
analog.com Rev. A | 267 of 312
Table 342. Timer Register Summary
Address Name Description Reset Access
0x40000000 GPT0_LOAD 16-bit synchronous load value 0x0000 R/W
0x40000004 GPT0_CURCNT 16-bit timer synchronous value 0x0000 R
0x40000008 GPT0_CTL Control 0x000A R/W
0x4000000C GPT0_CLRINT Clear interrupt 0x0000 W
0x40000010 GPT0_CAPTURE Capture 0x0000 R
0x40000014 GPT0_ALOAD 16-bit asynchronous load value 0x0000 R/W
0x40000018 GPT0_ACURCNT 16-bit timer asynchronous value 0x0000 R
0x4000001C GPT0_STAT Status 0x0000 R
0x40000400 GPT1_LOAD 16-bit synchronous load value 0x0000 R/W
0x40000404 GPT1_CURCNT 16-bit timer synchronous value 0x0000 R
0x40000408 GPT1_CTL Control 0x000A R/W
0x4000040C GPT1_CLRINT Clear interrupt 0x0000 W
0x40000410 GPT1_CAPTURE Capture 0x0000 R
0x40000414 GPT1_ALOAD 16-bit asynchronous load value 0x0000 R/W
0x40000418 GPT1_ACURCNT 16-bit timer asynchronous value 0x0000 R
0x4000041C GPT1_STAT Status 0x0000 R
0x40000800 GPT2_LOAD 16-bit synchronous load value 0x0000 R/W
0x40000804 GPT2_CURCNT 16-bit timer synchronous value 0x0000 R
0x40000808 GPT2_CTL Control 0x000A R/W
0x4000080C GPT2_CLRINT Clear interrupt 0x0000 W
0x40000810 GPT2_CAPTURE Capture 0x0000 R
0x40000814 GPT2_ALOAD 16-bit asynchronous load value 0x0000 R/W
0x40000818 GPT2_ACURCNT 16-bit timer asynchronous value 0x0000 R
0x4000081C GPT2_STAT Status 0x0000 R
