Reference Manual ADuCM356
REGISTER SUMMARY: FLASH CACHE CONTROLLER
analog.com Rev. A | 189 of 312
Table 223. FLCC Register Summary
Address Name Description Reset Access
0x40018000 STAT Status 0x00000000 R/W
0x40018004 IEN Interrupt enable 0x40 R/W
0x40018008 CMD Command 0x00000000 R/W
0x4001800C KH_ADDR Write address 0x00000000 R/W
0x40018010 KH_DATA0 Write lower data 0xFFFFFFFF R/W
0x40018014 KH_DATA1 Write upper data 0xFFFFFFFF R/W
0x40018018 PAGE_ADDR0 Lower page address 0x00000000 R/W
0x4001801C PAGE_ADDR1 Upper page address 0x00000000 R/W
0x40018020 KEY Key 0x00000000 W
0x40018024 WR_ABORT_ADDR Write abort address 0xXXXXXXXX R
0x40018028 WRPROT Write protection 0xFFFFFFFF R/W
0x4001802C SIGNATURE Signature 0xXXXXXXXX R
0x40018030 UCFG User configuration 0x00000000 R/W
0x4001803C ABORT_EN_LO IRQ abort enable (lower bits) 0x00000000 R/W
0x40018040 ABORT_EN_HI IRQ abort enable (upper bits) 0x00000000 R/W
0x40018044 ECC_CFG ECC configuration 0x00000002 R/W
0x40018048 ECC_ADDR ECC status (address) 0x00000000 R
0x40018050 ADI_POR_SEC Analog Devices flash security 0x00000000 R/W
