Reference Manual ADuCM356

analog.com Rev. A | 207 of 312

ANALOG DEVICES IDENTIFICATION (DIGITAL DIE) REGISTER

Address: 0x40002020, Reset: 0x4144, Name: ADIID

Analog Devices Cortex device identification.

Table 249. Bit Descriptions for ADIID

Bits Bit Name Settings Description Reset Access

[15:0] VALUE Analog Devices Identification. Reads a fixed value of 0x4144 to indicate to debuggers that they are

connected to an Analog Devices implemented Cortex-based device.

0x4144 R

CHIP IDENTIFIER (DIGITAL DIE) REGISTER

Address: 0x40002024, Reset: 0x0284, Name: CHIPID

Chip identification for the digital die.

Table 250. Bit Descriptions for CHIPID

Bits Bit Name Settings Description Reset Access

[15:4] PARTID Part Identifier. 0x28 R

[3:0] REV Silicon Revision. 0x4 R

SERIAL WIRE DEBUG ENABLE REGISTER

Address: 0x40002040, Reset: 0x6E65, Name: SWDEN

This register is used to enable the SWD interface. This register is reset upon an internal power-on or an external pin reset. This register is not

affected by a software reset.

Table 251. Bit Descriptions for SWDEN

Bits Bit Name Settings Description Reset Access

[15:0] VALUE Enable SWD Interface. Writing this register with en (0x6E65) or EN (0x4E45) enables the SWD interface.

Writing this register with rp (0x7072) or RP (0x5052) disables the SWD interface. Writes of any other value

are ignored. This register cannot be modified when written with EN or RP. This register is reset by a POR or

pin reset, but not software or WDT reset.

0x6E65 W

ANALOG DEVICES IDENTIFICATION (ANALOG DIE) REGISTER

Address: 0x400C0400, Reset: 0x4144, Name: ADIID

Analog Devices identifier.

Table 252. Bit Descriptions for ADIID

Bits Bit Name Settings Description Reset Access

[15:0] ADIID Analog Devices Identifier. Always equals 0x4144. 0x4144 R

CHIP IDENTIFICATION (ANALOG DIE) REGISTER

Address: 0x400C0404, Reset: 0x5502, Name: CHIPID

Table 253. Bit Descriptions for CHIPID

Bits Bit Name Settings Description Reset Access

[15:4] PARTID Part Identifier. 0x550 R

[3:0] Revision Silicon Revision Number. 0x2 R
