Analog Devices ADuCM356 User Manual

Reference Manual ADuCM356
REGISTER DETAILS: PROGRAMMABLE SWITCHES
analog.com Rev. A | 125 of 312
Table 151. Bit Descriptions for NSWSTA (Continued)
Bits Bit Name Settings Description Reset Access
0 Switch open.
1 Switch closed.
1 N2STA Status of N2 Switch. 0x0 R
0 Switch open.
1 Switch closed.
0 N1STA Status of N1 Switch. 0x0 R
0 Switch open.
1 Switch closed.
TX SWITCH MATRIX STATUS REGISTER
Address: 0x400C21BC, Reset: 0x00000000, Name: TSWSTA
This register gives the status of the Tx switches shown in Figure 27.
Table 152. Bit Descriptions for TSWSTA
Bits Bit Name Settings Description Reset Access
[31:12] Reserved Reserved. 0x0 R
11 TR1STA Status of TR1 Switch. 0x0 R
0 Switch open.
1 Switch closed.
10 T11STA Status of T11 Switch. 0x0 R
0 Switch open.
1 Switch closed.
9 T10STA Status of T10 Switch. 0x0 R
0 Switch open.
1 Switch closed.
8 T9STA Status of T9 Switch. 0x0 R
0 Switch open.
1 Switch closed.
7 T8STA Status of T8 Switch. 0x0 R
0 Switch open.
1 Switch closed.
6 T7STA Status of T7 Switch. 0x0 R
0 Switch open.
1 Switch closed.
5 T6STA Status of T6 Switch. 0x0 R
0 Switch open.
1 Switch closed.
4 T5STA Status of T5 Switch. 0x0 R
0 Switch open.
1 Switch closed.
3 T4STA Status of T4 Switch. 0x0 R
0 Switch open.
1 Switch closed.
2 T3STA Status of T3 Switch. 0x0 R
0 Switch open.
1 Switch closed.
1 T2STA Status of T2 Switch. 0x0 R
