Reference Manual ADuCM356
AFE INTERRUPTS
analog.com Rev. A | 137 of 312
INTERRUPT REGISTERS
Table 174. Interrupt Registers Summary
Address Name Description Reset Access
0x400C3000 INTCPOL Interrupt polarity register 0x00000000 R/W
0x400C3004 INTCCLR Interrupt clear register 0x00000000 W
0x400C3008 INTCSEL0 Interrupt controller select register 0x00002000 R/W
0x400C300C INTCSEL1 Interrupt controller select register 0x00002000 R/W
0x400C3010 INTCFLAG0 Interrupt controller flag register 0x00000000 R
0x400C3014 INTCFLAG1 Interrupt controller flag register 0x00000000 R
0x400C209C AFEGENINTSTA Analog generation interrupt register 0x00000010 R/W1C
Interrupt Polarity Register
Address: 0x400C3000, Reset: 0x00000000, Name: INTCPOL
Table 175. Bit Descriptions for INTCPOL Register
Bits Bit Name Settings Description Reset Access
[31:1] Reserved Reserved. 0x0 R
0 INTPOL Interrupt Polarity. 0x0 R/W
0 Output negative edge interrupt.
1 Output positive edge interrupt.
Interrupt Clear Register
Address: 0x400C3004, Reset: 0x00000000, Name: INTCCLR
Table 176. Bit Descriptions for INTCCLR Register
Bits Bit Name Description Reset Access
31 INTCLR31 Attempt to Break Interrupt (IRQ). Write 1 to clear. 0x0 W
30 Reserved Reserved. 0x0 W
29 INTCLR29 Outlier IRQ. Write 1 to clear. 0x0 W
28 Reserved Reserved. 0x0 W
27 INTCLR27 Data FIFO Underflow IRQ. Write 1 to clear. 0x0 W
26 INTCLR26 Data FIFO Overflow IRQ. Write 1 to clear. 0x0 W
25 INTCLR25 Data FIFO Threshold IRQ. Write 1 to clear. 0x0 W
24 INTCLR24 Data FIFO Empty IRQ. Write 1 to clear. 0x0 W
23 INTCLR23 Data FIFO Full IRQ. Write 1 to clear. 0x0 W
22 Reserved Reserved. 0x0 W
17 INTCLR17 Sequencer Timeout Error IRQ. Write 1 to clear. 0x0 W
16 INTCLR16 Sequencer Timeout Finished IRQ. Write 1 to clear. 0x0 W
15 INTCLR15 End of Sequence IRQ. Write 1 to clear. 0x0 W
14 Reserved Reserved. 0x0 W
13 INTCLR13 Boot Load Done IRQ. Write 1 to clear. 0x0 W
12 INTCLR12 Custom Interrupt 3. Write 1 to clear. Not applicable Not applicable
11 INTCLR11 Custom Interrupt 2. Write 1 to clear. Not applicable Not applicable
10 INTCLR10 Custom Interrupt 1. Write 1 to clear. Not applicable Not applicable
9 INTCLR9 Custom Interrupt 0. Write 1 to clear. Not applicable Not applicable
8 Reserved Reserved. 0x0 W
7 INTCLR7 Mean IRQ. Write 1 to clear. 0x0 W
