Reference Manual ADuCM356
SYSTEM EXCEPTIONS AND PERIPHERAL INTERRUPTS
analog.com Rev. A | 39 of 312
CORTEX-M3 AND FAULT MANAGEMENT
The ADuCM356 integrates an Arm Cortex-M3 processor, which
supports several system exceptions and interrupts generated by
peripherals. Table 40 lists the Arm Cortex-M3 processor system
exceptions.
Table 40. System Exceptions
Exception Number Type Priority Description
1 Reset −3 (highest) Any reset.
2 NMI −2 Nonmaskable interrupt connected to a combination of logical ORs of DVDD_REG pin undervoltage
or AVDD_DD pin undervoltage. See Table 23.
3 Hard fault −1 All fault conditions if the corresponding fault handler is not enabled.
4 Memory management
fault
Programmable Access to invalid locations.
5 Bus fault Programmable Prefetch fault, memory access fault, data abort, and other address or memory related faults.
6 Usage fault Programmable Same as undefined instruction executed or invalid state transition attempt.
7 to 10 Reserved Not applicable Reserved.
11 SVCALL Programmable System service call with supervisor mode call (SVC) instruction. Used for system function calls.
12 Debug monitor Programmable Debug monitor for breakpoint, watchpoint, or external debug requests.
13 Reserved Not applicable Reserved.
14 PENDSV Programmable Pendable request for system service. Used for queuing system calls until other tasks and interrupts
are serviced.
15 SYSTICK Programmable System tick timer.
The NVIC controls the peripheral interrupts, which are listed in
Table 41. All interrupt sources can wake up the Arm Cortex-M3 core
from flexi mode. Only a limited number of interrupts can wake up
the processor from hibernate mode, as shown in Table 41. When
the device is woken up from flexi or hibernate mode, it returns to
active mode. If the processor enters flexi or hibernate mode while
the processor is in an interrupt handler, only an interrupt source
with a higher priority than the current interrupt can wake up the
device. Higher priority means having a higher value in a bit setting
in the Cortex IPRx registers.
Two steps are usually required to configure an interrupt as follows:
1. Configure a peripheral to generate an interrupt request to the
NVIC.
2. Configure the NVIC for that peripheral request.
Table 41. Interrupt Vectors
Exception Number IRQx Vector
Wake Up From
Flexi Hibernate
16 IRQ0 Digital Die Real-Time Clock 1, wake-up timer, hibernate RTC Yes Yes
17 IRQ1 Reserved Not applicable Not applicable
18 IRQ2 External Interrupt 1 (SYS_WAKE) Yes Yes
19 IRQ3 Reserved Not applicable Not applicable
20 IRQ4 External Interrupt 3, UART receive wake-up interrupt, and INTCxxx register interrupt Yes Yes
21 IRQ5 Reserved Yes No
22 IRQ6 Digital Die DVDD_REG pin overrange Yes No
23 IRQ7 DVDD pin voltage range Yes Yes
24 IRQ8 Reserved Not applicable Not applicable
25 IRQ9 GPIO Interrupt A Yes No
26 IRQ10 GPIO Interrupt B Yes No
27 IRQ11 Digital Die General-Purpose Timer 0 Yes No
28 IRQ12 Digital Die General-Purpose Timer 1 Yes No
29 IRQ13 Flash controller Yes No
30 IRQ14 UART0 Yes No
31 IRQ15 SPI0 Yes
1
No
32 IRQ16 SPI1 Yes
1
No
33 IRQ17 I
2
C target Yes
1
No
34 IRQ18 I
2
C initiator Yes
1
No
