Reference Manual ADuCM356
REGISTER DETAILS: GENERAL-PURPOSE TIMERS
analog.com Rev. A | 268 of 312
16-BIT SYNCHRONOUS LOAD VALUE REGISTERS
Address: 0x40000000, Reset: 0x0000, Name: GPT0_LOAD
Address: 0x40000400, Reset: 0x0000, Name: GPT1_LOAD
Address: 0x40000800, Reset: 0x0000, Name: GPT2_LOAD
Table 343. Bit Descriptions for GPT0_LOAD, GPT1_LOAD, GPT2_LOAD
Bits Bit Name Settings Description Reset Access
[15:0] LOAD Load Value. The up or down counter is periodically loaded with this value if periodic mode is selected
(GPTx_CTL, Bit 3 = 1). This bit writes during up or down counter timeout events that are delayed until the
event passes.
0x0000 R/W
16-BIT TIMER SYNCHRONOUS VALUE REGISTERS
Address: 0x40000004, Reset: 0x0000, Name: GPT0_CURCNT
Address: 0x40000404, Reset: 0x0000, Name: GPT1_CURCNT
Address: 0x40000804, Reset: 0x0000, Name: GPT2_CURCNT
Table 344. Bit Descriptions for GPT0_CURCNT, GPT1_CURCNT, GPT2_CURCNT
Bits Bit Name Settings Description Reset Access
[15:0] VALUE Current Count. Reflects the current up or down counter value. Value delayed by two PCLK cycles due to
clock synchronizers.
0x0000 R
CONTROL REGISTERS
Address: 0x40000008, Reset: 0x000A, Name: GPT0_CTL
Address: 0x40000408, Reset: 0x000A, Name: GPT1_CTL
Address: 0x40000808, Reset: 0x000A, Name: GPT2_CTL
Table 345. Bit Descriptions for GPT0_CTL, GPT1_CTL, GPT2_CTL
Bits Bit Name Settings Description Reset Access
15 SYNCBYP Synchronization Bypass. Used to bypass the synchronization logic within the block. Use only when both
the general-purpose timer and the CPU are clocked from the same source.
0x0 R/W
14 Reserved Reserved. 0x0 R
13 EVTEN Event Select. Used to enable and to disable the capture of events. This bit is used in conjunction with
the event select range. When a selected event occurs, the current value of the up or down counter is
captured in GPTx_CAPTURE.
0x0 R/W
0 Events are not captured.
1 Events are captured.
[12:8] EVTRANGE Event Select Range. Timer event select range (0 to 31). 0x0 R/W
7 RLD Reload Control. This bit is only used for periodic mode. This bit allows the user to select whether the up or
down counter is reset only on a timeout event or also when CLRINT, Bit 0 is set.
0x0 R/W
0 Up or down counter is only reset on a timeout event.
1 Resets the up down counter when CLRINT, Bit 0 is set.
[6:5] CLK Clock Select. Used to select a timer clock from the four available clock sources. 0x0 R/W
00 PCLK.
01 High frequency oscillator. 26 MHz high frequency oscillator.
10 Low frequency oscillator. 32 kHz low frequency oscillator.
11 Reserved.
