Analog Devices ADuCM356 User Manual

Reference Manual ADuCM356
REGISTER SUMMARY: HIGH-SPEED DAC CIRCUITS
analog.com Rev. A | 108 of 312
Table 128. High-Speed DAC Control Register Summary
Address Name Description Reset Access
0x400C2010 HSDACCON High-speed DAC configuration 0x0000001E R/W
0x400C2048 HSDACDAT Direct write to DAC output control value 0x00000800 R/W
0x400C2104 DACDCBUFCON DAC DC buffer configuration 0x00000000 R/W
0x400C2260 DACGAIN DAC gain 0x00000800 R/W
0x400C2264 DACOFFSETATTEN DAC offset with attenuator enabled (low-power mode) 0x00000000 R/W
0x400C2268 DACOFFSET DAC offset with attenuator disabled (low-power mode) 0x00000000 R/W
0x400C22B8 DACOFFSETATTENHP DAC offset with attenuator enabled (high-power mode) 0x00000000 R/W
0x400C22BC DACOFFSETHP DAC offset with attenuator disabled (high-power mode) 0x00000000 R/W
Table 129. Waveform Generator for High-Speed DAC Register Summary
Address Name Description Reset Access
0x400C2014 WGCON Waveform generator configuration 0x00000030 R/W
0x400C2030 WGFCW Waveform generator for sinusoid frequency control word 0x00000000 R/W
0x400C2034 WGPHASE Waveform generator for sinusoid phase offset 0x00000000 R/W
0x400C2038 WGOFFSET Waveform generator for sinusoid offset 0x00000000 R/W
0x400C203C WGAMPLITUDE Waveform generator for sinusoid amplitude 0x00000000 R/W
