Reference Manual ADuCM356
REGISTER DETAILS: UART
analog.com Rev. A | 260 of 312
Table 327. Bit Descriptions for COMLSR (Continued)
Bits Bit Name Settings Description Reset Access
0 Receive data has not been overwritten.
1 Receive data was overwritten by new data before COMRX was read.
0 DR Data Ready. This bit is cleared only by reading COMRX. If set, this bit does not self clear. 0x0 RC
0 COMRX does not contain new receive data.
1 COMRX contains receive data that needs to be read.
MODEM STATUS REGISTER
Address: 0x40005018, Reset: 0x0000, Name: COMMSR
Table 328. Bit Descriptions for COMMSR
Bits Bit Name Settings Description Reset Access
[15:4] Reserved Reserved. 0x0 R
3 DDCD Delta DCD. If set, this bit self clears after COMMSR is read. 0x0 R
0 DCD has not changed state since COMMSR was last read.
1 DCD changed state since COMMSR was last read.
2 TERI Trailing Edge Ring Indicator. If set, this bit self clears after COMMSR is read. 0x0 R
0 RI has not changed from 0 to 1 since COMMSR was last read.
1 RI changed from 0 to 1 since COMMSR was last read.
1 DDSR Delta DSR. If set, this bit self clears after COMMSR is read. 0x0 R
0 DSR has not changed state since COMMSR was last read.
1 DSR changed state since COMMSR was last read.
0 DCTS Delta CTS. If set, this bit self clears after COMMSR is read. 0x0 R
0 CTS has not changed state since COMMSR was last read.
1 CTS changed state since COMMSR was last read.
SCRATCH BUFFER REGISTER
Address: 0x4000501C, Reset: 0x0000, Name: COMSCR
Table 329. Bit Descriptions for COMSCR
Bits Bit Name Settings Description Reset Access
[15:8] Reserved Reserved. 0x0 R
[7:0] SCR Scratch. The scratch register is an 8-bit register used to store intermediate results. The value contained in
the scratch register does not affect UART functionality or performance. Only eight bits of this register are
implemented. Bits[15:8] are read only and always return 0x00 when read. SCR is writable with any value
from 0 to 255. A read returns the last value written.
0x0 R/W
FIFO CONTROL REGISTER
Address: 0x40005020, Reset: 0x0000, Name: COMFCR
Table 330. Bit Descriptions for COMFCR
Bits Bit Name Settings Description Reset Access
[15:8] Reserved Reserved. 0x0 R
[7:6] RFTRIG Receive FIFO Trigger Level. 0x0 R/W
00 1 byte to trigger receive interrupt.
01 4 bytes to trigger receive interrupt.
10 8 bytes to trigger receive interrupt.
11 14 bytes to trigger receive interrupt.
[5:4] Reserved Reserved. 0x0 R
