Page #120 background imageLoading...
Page #120 background image
Reference Manual ADuCM356
REGISTER DETAILS: PROGRAMMABLE SWITCHES
analog.com Rev. A | 120 of 312
Table 146. Bit Descriptions for NSWFULLCON (Continued)
Bits Bit Name Settings Description Reset Access
3 N4 Control of N4 Switch. Set to close the N4 switch, clear to open. Connects the N node of the excitation
amplifier to the AIN3/BUF_VREF1V8 pin.
0x0 R/W
0 Switch open.
1 Switch closed.
2 N3 Control of N3 Switch. Set to close the N3 switch, clear to open. Connects the N node of the excitation
amplifier to the AIN2 pin.
0x0 R/W
0 Switch open.
1 Switch closed.
1 N2 Control of N2 Switch. Set to close the N2 switch, clear to open. Connects the N node of the excitation
amplifier to the AIN1 pin.
0x0 R/W
0 Switch open.
1 Switch closed.
0 N1 Control of N1 Switch. Set to close the N1 switch, clear to open. Connects the N node of the excitation
amplifier to the AIN0 pin.
0x0 R/W
0 Switch open.
1 Switch closed.
PX SWITCH MATRIX FULL CONFIGURATION REGISTER
Address: 0x400C2158, Reset: 0x00000000, Name: PSWFULLCON
This register allows individual control of the Px switches. The bit names are the same as the switch names shown in Figure 27. SWCON, Bit 16
must be set to 1 after writing to this register for the new switch settings to take effect.
Table 147. Bit Descriptions for PSWFULLCON
Bits Bit Name Settings Description Reset Access
[31:15] Reserved Reserved. 0x0 R
14 PL2 Control of PL2 Switch. Control of PL2 switch. 0x0 R/W
0 Switch open.
1 Switch closed.
13 PL Control of PL Switch. Shorts the D node and P node of the excitation amplifiers together. 0x0 R/W
0 Switch open.
1 Switch closed.
12 Reserved Reserved. 0x0 R/W
11 P12 Control of P12 Switch. Connects the P node of the excitation amplifier to the CE1 pin. 0x0 R/W
0 Switch open.
1 Switch closed.
10 P11 Control of P11 Switch. Connects the P node of the excitation amplifier to the CE0 pin. 0x0 R/W
0 Switch open.
1 Switch closed.
9 P10 Control of P10 Switch. Connects the P node of the excitation amplifier to the DE1 pin. 0x0 R/W
0 Switch open.
1 Switch closed.
8 P9 Control of P9 Switch. Connects the P node of the excitation amplifier to the SE1 pin. 0x0 R/W
0 Switch open.
1 Switch closed.
7 P8 Control of P8 Switch. Connects the P node of the excitation amplifier to the DE0 pin. 0x0 R/W
0 Switch open.
1 Switch closed.
6 P7 Control of P7 Switch. Connects the P node of the excitation amplifier to the SE0 pin. 0x0 R/W
