Reference Manual ADuCM356
REGISTER SUMMARY: PROGRAMMABLE SWITCHES
analog.com Rev. A | 116 of 312
The status of all the switches can be read from the switch sta-
tus registers at any time. These statuses indicate whether each
switch is open or closed. The switch status registers are DSWSTA,
PSWSTA, NSWSTA, and TSWSTA.
Table 143. Programmable Switch Matrix Register Summary
Address Name Description Reset Access
0x400C200C SWCON Switch matrix configuration 0x0000FFFF R/W
0x400C2150 DSWFULLCON Dx switch matrix full configuration 0x00000000 R/W
0x400C2154 NSWFULLCON Nx switch matrix full configuration 0x00000000 R/W
0x400C2158 PSWFULLCON Px switch matrix full configuration 0x00000000 R/W
0x400C215C TSWFULLCON Tx switch matrix full configuration 0x00000000 R/W
0x400C21B0 DSWSTA Dx switch matrix status 0x00000000 R
0x400C21B4 PSWSTA Px switch matrix status 0x00000000 R
0x400C21B8 NSWSTA Nx switch matrix status 0x00000000 R
0x400C21BC TSWSTA Tx switch matrix status 0x00000000 R
