Reference Manual ADuCM356
REGISTER SUMMARY: ANALOG DIE GENERAL-PURPOSE TIMERS
analog.com Rev. A | 273 of 312
Table 351. AGPT0 Register Summary
Address Name Description Reset Access
0x400C0D00 LD0 16-bit load value 0x0000 R/W
0x400C0D04 VAL0 16-bit timer value 0x0000 R
0x400C0D08 CON0 Control 0x000A R/W
0x400C0D0C CLRI0 Clear interrupt 0x0000 W
0x400C0D14 ALD0 16-bit load value, asynchronous 0x0000 R/W
0x400C0D18 AVAL0 16-bit timer value, asynchronous 0x0000 R
0x400C0D1C STA0 Status 0x0000 R
0x400C0D20 PWMCON0 PWM control 0x0000 R/W
0x400C0D24 PWMMAT0 PWM match value 0x0000 R/W
0x400C0D28 INTEN Interrupt enable 0x0000 R/W
Table 352. AGPT1 Register Summary
Address Name Description Reset Access
0x400C0E00 LOAD 16-bit load value 0x0000 R/W
0x400C0E04 CURCNT 16-bit timer value 0x0000 R
0x400C0E08 CTL Control 0x000A R/W
0x400C0E0C CLRINT Clear interrupt 0x0000 W
0x400C0E14 ALOAD 16-bit load value, asynchronous 0x0000 R/W
0x400C0E18 ACURCNT 16-bit timer value, asynchronous 0x0000 R
0x400C0E1C STAT Status 0x0000 R
0x400C0E20 PWMCTL PWM control 0x0000 R/W
0x400C0E24 PWMMATCH PWM match value 0x0000 R/W
