REGISTER DETAILS: PROGRAMMABLE SWITCHES
analog.com Rev. A | 124 of 312
Table 150. Bit Descriptions for PSWSTA (Continued)
Bits Bit Name Settings Description Reset Access
0 Switch open.
1 Switch closed.
2 P3STA Status of P3 Switch. 0x0 R
0 Switch open.
1 Switch closed.
1 P2STA Status of P2 Switch. 0x0 R
0 Switch open.
1 Switch closed.
0 PR0STA PR0 Switch Control. 0x0 R
0 Switch open.
1 Switch closed.
NX SWITCH MATRIX STATUS REGISTER
Address: 0x400C21B8, Reset: 0x00000000, Name: NSWSTA
This register gives the status of the Nx switches shown in Figure 27.
Table 151. Bit Descriptions for NSWSTA
Bits Bit Name Settings Description Reset Access
[31:12] Reserved Reserved. 0x0 R
11 NL2STA Status of NL2 Switch. 0x0 R
0 Switch open.
1 Switch closed.
10 NLSTA Status of NL Switch. 0x0 R
0 Switch open.
1 Switch closed.
9 NR1STA Status of NR1 Switch. 0x0 R
0 Switch open.
1 Switch closed.
8 N9STA Status of N9 Switch. 0x0 R
0 Switch open.
1 Switch closed.
7 N8STA Status of N8 Switch. 0x0 R
0 Switch open.
1 Switch closed.
6 N7STA Status of N7 Switch. 0x0 R
0 Switch open.
1 Switch closed.
5 N6STA Status of N6 Switch. 0x0 R
0 Switch open.
1 Switch closed.
4 N5STA Status of N5 Switch. 0x0 R
0 Switch open.
1 Switch closed.
3 N4STA Status of N4 Switch. 0x0 R
0 Switch open.
1 Switch closed.
2 N3STA Status of N3 Switch. 0x0 R
