Reference Manual ADuCM356
SEQUENCER
analog.com Rev. A | 135 of 312
Table 170. Bit Descriptions for SEQ1INFO Register
Bits Bit Name Description Reset Access
[31:27] Reserved Reserved. 0x0 R
[26:16] SEQ1INSTNUM SEQ1 Instruction Number. 0x0 R/W
[15:11] Reserved Reserved. 0x0 R
[10:0] SEQ1STARTADDR SEQ1 Start Address. 0x0 R/W
Command and Data FIFO Internal Data Count Register
Address: 0x400C2200, Reset: 0x00000000, Name: FIFOCNTSTA
Table 171. Bit Descriptions for FIFOCNTSTA Register
Bits Bit Name Description Reset Access
[31:27] Reserved Reserved. 0x0 R
[26:16] DATAFIFOCNTSTA[10:0] Current Number of Words in the Data FIFO. 0x0 R
[15:0] Reserved Reserved. 0x0 R
Trigger Sequence Register
Address: 0x400C0430, Reset: 0x0000, Name: TRIGSEQ
Table 172. Bit Descriptions for TRIGSEQ Register
Bits Bit Name Description Reset Access
[15:4] Reserved Reserved. 0x0 R
3 TRIG3 Trigger Sequence 3. 0x0 R/W
2 TRIG2 Trigger Sequence 2. 0x0 R/W
1 TRIG1 Trigger Sequence 1. 0x0 R/W
0 TRIG0 Trigger Sequence 0. 0x0 R/WS
