Reference Manual ADuCM356
SLEEP AND WAKE-UP TIMER
analog.com Rev. A | 145 of 312
Table 181. Bit Descriptions for CON Register (Continued)
Bits Bit Name Settings Description Reset Access
[5:4] RESERVED Reserved. 0x0 R
[3:1] ENDSEQ End Sequence. These bits select one of the SEQORDER bits to end the timing sequence. 0x0 R/W
000 The sleep and wake-up timer stops at Sequence A and then goes back to Sequence A.
001 The sleep and wake-up timer stops at Sequence B and then goes back to Sequence A.
010 The sleep and wake-up timer stops at Sequence C and then goes back to Sequence A.
011 The sleep and wake-up timer stops at Sequence D and then goes back to Sequence A.
100 The sleep and wake-up timer stops at Sequence E and then goes back to Sequence A.
101 The sleep and wake-up timer stops at Sequence F and then goes back to Sequence A.
110 The sleep and wake-up timer stops at Sequence G and then goes back to Sequence A.
111 The sleep and wake-up timer stops at Sequence H and then goes back to Sequence A.
0 EN Sleep and Wake-Up Timer Enable Bit. 0x0 R/W
0 Disables the sleep and wake-up timer.
1 Enables the sleep and wake-up timer.
Order Control Register
Address: 0x400C0804, Reset: 0x0000, Name: SEQORDER
The SEQORDER register controls the command sequence execution order.
Table 182. Bit Descriptions for SEQORDER Register
Bits Bit Name Settings Description Reset Access
[15:14] SEQH Sequence H Configuration. These bits select SEQ0, SEQ1, SEQ2, or SEQ3 for Timer Sequence H. 0x0 R/W
00 Fills in SEQ0.
01 Fills in SEQ1.
10 Fills in SEQ2.
11 Fills in SEQ3.
[13:12] SEQG Sequence G Configuration. These bits select SEQ0, SEQ1, SEQ2, or SEQ3 for Timer Sequence G. 0x0 R/W
00 Fills in SEQ0.
01 Fills in SEQ1.
10 Fills in SEQ2.
11 Fills in SEQ3.
[11:10] SEQF Sequence F Configuration. These bits select SEQ0, SEQ1, SEQ2, or SEQ3 for Timer Sequence F. 0x0 R/W
00 Fills in SEQ0.
01 Fills in SEQ1.
10 Fills in SEQ2.
11 Fills in SEQ3.
[9:8] SEQE Sequence E Configuration. These bits select SEQ0, SEQ1, SEQ2, or SEQ3 for Timer Sequence E. 0x0 R/W
00 Fills in SEQ0.
01 Fills in SEQ1.
10 Fills in SEQ2.
11 Fills in SEQ3.
[7:6] SEQD Sequence D Configuration. These bits select SEQ0, SEQ1, SEQ2, or SEQ3 for Timer Sequence D. 0x0 R/W
00 Fills in SEQ0.
01 Fills in SEQ1.
10 Fills in SEQ2.
11 Fills in SEQ3.
[5:4] SEQC Sequence C Configuration. These bits select SEQ0, SEQ1, SEQ2, or SEQ3 for Timer Sequence C. 0x0 R/W
00 Fills in SEQ0.
