Programmers model
Record GICT_ERR<n>STATUS.IERR (syndrome) GICT_ERR<n>STATUS
.SERR
Value and description of
GICT_ERR<n>MISC0.Data (other bits
RES0)
Always packed from 0 (lowest = 0)
Software error
(0)
0x40, SYN_LPI_PROP_READ_FAIL
An attempt was made to read properties for a single
interrupt where an error response was received with
the data.
0x12 Target, bits[29:16]
ID, bits[15:0]
Software error
(0)
0x41, SYN_PT_PROP_READ_FAIL
An attempt was made to read properties for a block of
interrupts where an error response was received with
the data.
0x12 Target, bits[29:16]
ID, bits[15:0]
Software error
(0)
0x42, SYN_PT_COARSE_MAP_READ_FAIL
An attempt was made to read the coarse map for a
target where an error response was received with the
data.
0x12 Target, bits[29:16]
Software error
(0)
0x43, SYN_PT_COARSE_MAP_WRITE_FAIL
An attempt was made to write the coarse map for a
target with an error received with the write response.
0x12 Target, bits[29:16]
Software error
(0)
0x44, SYN_PT_TABLE_READ_FAIL
An attempt was made to read a block of interrupts
from a Pending table, where an error response was
received with the data.
0x12 Target, bits[29:16]
ID, bits[15:0]
Software error
(0)
0x45, SYN_PT_TABLE_WRITE_FAIL
An attempt was made to write-back a block of
interrupts from a Pending table with an error received
with the write response.
0x12 Target, bits[29:16]
ID, bits[15:0]
Software error
(0)
0x46, SYN_PT_SUB_TABLE_READ_FAIL
An attempt was made to read a subblock of interrupts
from a Pending table, where an error response was
received with the data.
0x12 Target, bits[29:16]
ID, bits[15:0]
Software error
(0)
0x47, SYN_PT_TABLE_WRITE_FAIL_BYTE
An attempt was made to write-back a subblock of
interrupts from a Pending table, with an error received
with the write response.
0x12 Target, bits[29:16]
ID, bits[15:0]
Correctable
SPI RAM
errors (1)
0x00 0x7
Uncorrectable
SPI RAM
errors (2)
0x00 0x7
See Table 4-9: SPI RAM errors, records
1-2 on page 76
Correctable
SGI RAM
errors (3)
0x00 0x7
Uncorrectable
SGI RAM
errors (4)
0x00 0x7
See Table 4-10: SGI RAM errors,
records 3-4 on page 78
Reserved (5) - - -
Reserved (6) - - -
Correctable
PPI RAM
errors (7)
0x00 0x7 See Table 4-11: PPI RAM errors,
records 7-8 on page 79
