Austro Engine E4 Series User Manual

E4 Series
Maintenance Manual
Electrical Power
Page 240
E4.08.04
Rev. 29
24-31-00
01-Jul-2020
I. Mark the inspected Alternator E4A-91-400-000
For each check of the Brush Holder Assembly E4A-91-410-000, engrave an X (cross) on the bottom of
the alternator. Fig. 24 - 49 shows dimension of the marking.
Fig. 24 - 50 Alternator bottom side with marking
To increase the visibility of the cross, you can additionally mark with a permanent marker.
Do not use stickers for marking!
~10 mm
~10 mm
X (Cross)
Fig. 24 - 49 Dimension of marking
